UHD Signage Display with
LG webOS Platform and Advanced Security

High Resolution Display
It offers a resolution that is four times higher than FHD, satisfying customers visually. Additionally, the anti-glare coating on the screen reduces screen reflection in bright lighting environments, increasing visibility and legibility, providing customers with a comfortable screen.

Sturdy Design with Fire Flame Resistance
The outer cover of the product is designed to effectively resist fire flame spread, making the product a great fit for installation in public spaces.

* Based on third party testing, the case top and back cover of the product are classified Class A1 (case top) and A2 (back cover) under EN13501-1, Class 1 under BS476 Part 7.

Convenient webOS Platform
The UH5N-M is equipped with a high-performance SoC that allows for multiple tasks to be performed without a separate media player. The webOS platform provides app development tools with an intuitive UI that enhances user convenience, enabling easy connection with external sensors and webOS partner apps to create an SI-friendly environment.

Design for Space Utilization
Designed with thin bezels and simple cable management, the UH5N-M saves space. With specialized hidden power inlets, it can be installed close to the wall, leaving only about 13 mm of space with the slim bracket.

Durability that Provides Reliability
Optimized for business environments, the UH5N-M is protected against salt, dust, iron powder and humidity thanks to conformal coating on power board, allowing for stable operation. Also, its customer-centric features, such as IP5x and Shock Monitoring, provide both reliability and satisfaction.

Enhanced Security Features
The UH5N-M provides security features, including LG's Enhanced Kernel Protection (EKP) technology, protecting important data from external access or attacks. LG UHD Signage also holds reliable certification in the field of information security, maintaining customers' data and businesses securely. For example, this model is ISO/IEC 15408 Common Criteria EAL2 Certified.

Sustainability
With a commitment to innovation and sustainability, LG is continuously striving to create a better future for manufacturers, consumers, and future generations. With a focus on minimizing waste, maximizing recycling, and efficient power management, LG actively strives for sustainability, obtaining various certifications such as FCC EMC Class B.

SuperSign Solutions
SuperSign is an integrated and intuitive content management solution for creative and organized digital signage content in your space, connecting customers to a range of services with convenient user experiences. There are a variety of versions such as SuperSign Cloud, so discover and enjoy the version that best fits you.

Specification

Product
Product id	1005749
Brand	LG Electronics
Partnr	65UH5N-M
EAN/UPC code	8806096398401
Warranty (months)	24 months
Display
Display diagonal	65 inch
LED backlight	Y
LED backlighting type	Edge-LED
Display resolution	3840 x 2160 Pixels
Display brightness	500 cd/m²
HD type	4K Ultra HD
Touchscreen	N
Native aspect ratio	16:9
Response time	8 ms
Contrast ratio (typical)	1100:1
Contrast ratio (dynamic)	1000000:1
Viewing angle, horizontal	178 °
Viewing angle, vertical	178 °
Display number of colours	1.07 billion colours
Panel life	50000 uur
Native refresh rate	60 Hz
Haze rate	28 procent
Colour depth	10 Bit
Colour gamut	95 procent
Panel type	IPS
Ports & interfaces
HDMI ports quantity	3
HDMI input ports quantity	3
DVI port	N
DisplayPorts quantity	1
USB port	Y
USB ports quantity	2
USB version	2.0
Ethernet LAN	Y
Ethernet LAN (RJ-45) ports	1
Wi-Fi	Y
RS-232C	Y
Remote (IR) input	1
Audio
Built-in speaker(s)	Y
RMS rated power	20 W
Design
Design	Digital signage flat panel
Product colour	Black
Placement supported	Indoor
Orientation	Horizontal/Vertical
Screen shape	Flat screen
VESA mounting	Y
Panel mounting interface	200 x 200 mm
Bezel width (top)	8.9 mm
Bezel colour	Black
Bezel width (side)	8.9 mm
Bezel width (bottom)	12.9 mm
Performance
Purpose	Universal
Operating hours (hours/days)	24/7
Automatic brightness control	Y
HDCP	Y
HDCP version	1.4/2.2/2.3
International Protection (IP) code	IP5X
Power
Power consumption (typical)	130 W
Power consumption (standby)	0.5 W
Energy efficiency class (SDR)	G
AC input voltage	100 - 240 V
AC input frequency	50/60 Hz
Energy consumption (SDR) per 1000 hours	130 kWu
Heat dissipation	444 BTU/h
Energy efficiency scale	A to G
Computer system
Computer system	Y
Computer system type	System on Chip (SoC)
Internal memory	16 GB
Operating system installed	WebOS
Operating system version	6.0
Weight & dimensions
Display width	1450.3 mm
Display depth	29.7 mm
Display height	830.3 mm
Display weight	24200 g
Packaging data
Package width	1600 mm
Package depth	172 mm
Package height	970 mm
Package weight	30400 g
Packaging content
Handheld remote control	Y
Batteries included	Y
Cables included	Power
Operational conditions
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 80 procent
Features
Heat dissipation (max)	699 BTU/h
Technical details
Real Time Clock (RTC)	Y
Other features
USB connector type	USB Type-A
Audio output	1
Display technology	LED
Power consumption (max)	205 W
Plug and Play	Y
