OPS-Sky-i5-d8/64/W10IoT A

NEC

Niet op voorraad

€ 1.103,70

€ 1.335,47 incl 21% BTW

OPS Slot-In PCs make digital signage simpler and more flexible without additional cables or devices
The full line-up of OPS Slot-in PCs supports a wide variety of applications starting from static content playback and ranging to the most demanding interactive, high resolution or resource hungry applications. The 6th generation Intel® processors (Skylake) deliver a new class of computing to power the next generation of slot-in computing. The OPS concept provides a compact and fully embedded solution ensuring that all connectors are integrated including power, video & audio signals and RS-232. All NEC large format displays (except E series 32" to 65"), PX and PH installation projectors feature this option slot

- Powerful possibilities - the 6th generation Intel® processors deliver a new class of computing with a host of new features to power the next generation of embedded computing.
- Intel ® HD graphics - provides Ultra HD resolution, intense detail and faster frame rates, giving you a remarkable visual experience.
- Industrial grade components - secure high reliability whilst withstanding extreme operating conditions.
- Seamless and fully embedded - as all connectors are inside the display including power, video, audio signals and RS-232, no external cables are required.
- High usage flexibility - thanks to wide connectivity such as 3 x USB, DisplayPort out, Gigabit ethernet and audio.
- Upgrade the power of your displays at any time - savings are possible by upgrading only your OPS device or your display with no need to change all hardware.
- A commitment to quality - tailored warranties available to best match long-term demands by extending standard warranty up to 5 years.
- Economical - enjoy more performance whilst consuming less power.

Specificaties

Product
Product id	652928
Merk	NEC
Partnr	100014546
EAN code	4719622274503
Processor
Frequentie van processor	2.7 GHz
Processorfamilie	Intel Core i5-6xxx
Processormodel	i5-6440EQ
Aantal processorkernen	4
Maximale turbofrequentie van processor	3.4 GHz
Processor socket	BGA 1440
Processor cache	6 MB
Processor cache type	Smart Cache
Systeembus	8 GT/s
Processor aantal threads	4
PCI Express slots versie	3.0
Processor lithografie	14 nm
Processor operating modes	64-bit
Stepping	R0
Bus type	DMI3
Codenaam processor	Skylake
Thermal Design Power (TDP)	45 W
Processorserie	Intel Core i5-6400 Mobile Series
Maximaal aantal PCI Express-lijnen	16
PCI Express configuraties	1x16,1x8+2x4,2x8
Tcase	100 °C
Tjunction	100 °C
Maximaal intern geheugen ondersteund door processor	64 GB
Conflictvrije processor	Y
Geheugentypen ondersteund door processor	DDR3L-SDRAM,DDR4-SDRAM,LPDDR3-SDRAM
Klokgeheugen-snelheden ondersteund door processor	1600,1866,2133 MHz
Geheugenbandbreedte ondersteund door de processor ( max)	34.1 GB/s
Geheugenkanalen ondersteund door processor	Dual
ECC ondersteund door processor	N
Geheugen
Intern geheugen	8 GB
Intern geheugentype	DDR4-SDRAM
Maximum intern geheugen	16 GB
Geheugenslots	2x SO-DIMM
Opslagmedia
Totale opslagcapaciteit	64 GB
Opslagmedia	SSD
Geïntegreerde geheugenkaartlezer	N
SSD interfaces	M.2
SSD capaciteit	64 GB
Grafisch
Ingebouwde grafische adapter	Y
On-board graphics adapter model	Intel HD Graphics 530
Maximaal geheugen ingebouwde grafische adapter	64 GB
Basisfrequentie ingebouwde grafische adapter	350 MHz
Graphics on-board -adapter dynamische frequentie (max)	1000 MHz
On-board grafische adapter DirectX-versie	12.0
On-board grafische adapter OpenGL versie	4.4
On-board grafische adapter ID	0x191B
Aparte grafische adapter	N
Discreet grafische adapter model	Not available
Aantal displays ondersteund (door on-board grafische adapter)	3
Netwerk
Wi-Fi	N
Bekabelingstechnologie	10/100/1000Base-T(X)
Ethernet LAN, data-overdrachtsnelheden	10,100,1000 Mbit/s
Wake-on-LAN	Y
Poorten & interfaces
Aantal poorten USB 3.2 Gen 1 (3.1 Gen 1) Type A	3
DVI-poort	N
Aantal DisplayPorts	1
Aantal Ethernet LAN (RJ-45)-poorten	1
Hoofdtelefoonuitgangen	1
Microfoon, line-in ingang	Y
Prestatie
Chipset moederbord	Intel HM170
Kleur van het product	Black
Audiochip	Realtek ALC887
Software
Inclusief besturingssysteem	Microsoft Windows 10 IoT Enterprise
Processor speciale functies
Ondersteunde instructie sets	AVX 2.0,SSE4.1,SSE4.2
Processorcode	SR2DU
Intel® Identity Protection Technology (Intel® IPT)	Y
Intel® Hyper Threading Technology (Intel® HT Technology)	N
Intel® Turbo Boost Technology	2.0
Intel® Quick Sync Video Technology	Y
Intel® InTru™ 3D Technology	Y
Intel® Wireless Display (Intel® WiDi)	Y
Intel® Clear Video HD Technology (Intel® CVT HD)	Y
Intel® Insider™	Y
Intel® AES New Instructions (Intel® AES-NI)	Y
Enhanced Intel SpeedStep Technology	Y
Execute Disable Bit	Y
Idle States	Y
Thermal Monitoring Technologies	Y
Intel® Trusted Execution Technology	Y
Intel® Enhanced Halt State	Y
Intel® Clear Video Technology for Mobile Internet Devices (Intel® CVT for MID)	Y
Intel® VT-x with Extended Page Tables (EPT)	Y
Ingebouwde opties beschikbaar	Y
Graphics & IMC lithografie	14 nm
Intel® TSX-NI	Y
Intel® Secure Key	Y
Intel® 64	Y
Intel® OS Guard	Y
Intel® Virtualization Technology for Directed I/O (VT-d)	Y
Intel® Clear Video-technologie	Y
Intel® Software Guard Extensions (Intel® SGX)	Y
Intel® HD Graphics	Y
Intel® Virtualization Technology (VT-x)	Y
Verpakkingsgrootte processor	42 x 28 mm
ARK ID processor	90425
Eisen aan de omgeving
Temperatuur, in bedrijf	0 - 35 °C
Relatieve luchtvochtigheid, in bedrijf	0 - 90 procent
Certificaten
Certificering	CE/FCC
Gewicht en omvang
Breedte	120 mm
Diepte	190 mm
Hoogte	30 mm
Gewicht	900 g
Breedte verpakking	190 mm
Diepte verpakking	260 mm
Hoogte verpakking	70 mm
Gewicht verpakking	1000 g
