Productivity, connectivity, and comfort in a curved 1500R 34” ultra wide QHD display
Professional users looking for a true productivity ally need look no further than the CU34P2A. This model is equipped with a curved 1500R 34” VA/3FL screen with 21:9 ultra wide QHD resolution and 300 cd/m2 brightness. Its rich, innovative features include wide viewing angles of 178°/178°, HDMI and DP compatibility, a USB 3.2 hub, and auto source input.

Specification

Product
Product id	707079
Brand	AOC
Partnr	CU34P2A
EAN/UPC code	4038986118224
Technical details
Sustainability certificates	RoHS, ENERGY STAR
Display
Display diagonal	34 inch
Display resolution	3440 x 1440 Pixels
Native aspect ratio	21:9
Panel type	VA
Display brightness (typical)	300 cd/m²
Response time	1 ms
HD type	Quad HD
Display technology	LED
Backlight type	W-LED
Display surface	Matt
Screen shape	Curved screen
Screen curvature rating	1500R
Screen curvature	1500 mm
Supported graphics resolutions	1920 x 1080 (HD 1080), 2560 x 1440, 3440 x 1440
Supported video modes	1080p, 1440p
Aspect ratio	21:9
Contrast ratio (typical)	3000:1
Contrast ratio (dynamic)	50000000:1
Maximum refresh rate	100 Hz
Viewing angle, horizontal	178 °
Viewing angle, vertical	178 °
Display number of colours	16.78 million colours
Pixel pitch	0.2745 x 0.2745 mm
Viewable size, horizontal	797.22 mm
Viewable size, vertical	333.72 mm
Colour depth	8 Bit
RGB colour space	sRGB
sRGB coverage (typical)	120 procent
NTSC coverage (typical)	85 procent
Adobe RGB coverage	89 procent
Performance
NVIDIA G-SYNC	N
AMD FreeSync	N
VESA Adaptive Sync support	Y
Flicker-free technology	Y
Low Blue Light technology	Y
Multimedia
Built-in speaker(s)	Y
Built-in camera	N
Number of speakers	2
RMS rated power	3 W
Design
Market positioning	Business
Product colour	Black
Frameless design	Y
Front bezel colour	Black
Detachable stand	Y
Feet colour	Black
Heavy metals free	Hg (mercury)
Certification	TCO'8, CE
Ports & interfaces
Built-in USB hub	Y
USB hub version	3.2 Gen 1 (3.1 Gen 1)
USB Type-A downstream ports quantity	4
DVI port	N
HDMI	Y
HDMI ports quantity	2
HDMI version	2.0
DisplayPorts quantity	1
DisplayPort version	1.2
Audio input	N
Headphone out	Y
Headphone outputs	1
Headphone connectivity	3.5 mm
Microphone in	Y
DC-in jack	Y
Ergonomics
VESA mounting	Y
Panel mounting interface	100 x 100 mm
Cable lock slot	Y
Cable lock slot type	Kensington
Height adjustment	Y
Height adjustment	150 mm
Swivelling	Y
Swivel angle range	0 - 180 °
Tiltable	Y
Tilt angle range	5.5 - 22 °
On Screen Display (OSD)	Y
On Screen Display (OSD) languages	CHI (SIMPL), CHI (TR), CZE, DEU, DUT, ENG, ESP, FIN, FRE, ITA, JPN, KOR, POL, POR, RUS, SER
Number of OSD languages	16
Plug and Play	Y
Packaging data
Stand included	Y
Cables included	AC, DisplayPort, HDMI
DisplayPort cable length	1.8 m
HDMI cable length	1.8 m
Package width	903 mm
Package depth	250 mm
Package height	527 mm
Package weight	12700 g
Package type	Box
Power
Energy efficiency class (SDR)	G
Energy consumption (SDR) per 1000 hours	40 kWu
Power consumption (typical)	55 W
Energy efficiency class (HDR)	G
Power consumption (standby)	0.5 W
Energy consumption (HDR) per 1000 hours	42 kWu
Power consumption (off)	0.3 W
AC input voltage	100 - 240 V
AC input frequency	50/60 Hz
Energy efficiency scale	A to G
External power adapter	N
Weight & dimensions
Width (with stand)	808.34 mm
Depth (with stand)	275.13 mm
Height (with stand)	611.53 mm
Weight (with stand)	9800 g
Width (without stand)	808.34 mm
Depth (without stand)	100.14 mm
Height (without stand)	367.45 mm
Weight (without stand)	9800 g
Other features
Recyclable packaging material	100 procent
