Marketing Features

- Avoids costly power problems by keeping your IT equipment and data protected and available.
Network grade power conditioning protects from damaging surges and disruptive noise. The double conversion architecture provides tight voltage regulation, frequency regulation , and zero transfer time to battery during power events.
- Low operating and maintenance costs with proven reliability and intelligent battery management.
Intelligent battery management, pioneered by APC, maximizes battery performance and life through intelligent, precision temperature compensated charging. Automatic self tests insure battery reliability and warn customers in advance of battery replacement. Convenient, easy to connect, hot-swappable battery modules provide battery replacement without powering down.
- Save time with easy and convenient remote accessibility.
Network manageable via serial, USB or optional Ethernet. Includes Powerchute® Network Shutdown Software for convenient monitoring and control, safe operating system shutdown, and innovative energy management capabilities.
- Peace of mind that comes with full equipment compatibility and reliability of a leader
Provides pure sine wave output which is recommended by server manufacturers using active power factor corrected (PFC) power supplies. Safety agency tested and approved means that you can deploy Smart-UPS with confidence that they meet or exceed the industry’s most rigorous standards.

Specification

Product
Product id	720075
Brand	American Power Conversion
Partnr	SRT5KRMXLT
EAN/UPC code	731304301509
Warranty (months)	3 years
Power
Replacement battery cartridge	APCRBC140
Input frequency	40 - 70 Hz
Technical details
Sustainability certificates	ENERGY STAR
Warranty period	3 jaar
Compliance certificates	RoHS
Features
UPS topology	Double-conversion (Online)
Output power capacity	4.25 VA
Output power	4250 W
Waveform	Sine
Input operation voltage (min)	100 V
Input operation voltage (max)	275 V
Output operation voltage (min)	208 V
Output operation voltage (max)	240 V
Output frequency	50/60 Hz
Surge energy rating	480 J
Heat dissipation	1047 BTU/h
Crest factor	3:1
Input current Total Harmonic Distortion (THD)	2 procent
Noise level	55 dB
Surge protection	Y
Web-based management	Y
Audible alarm(s)	Y
Auto-restart	Y
Ports & interfaces
AC outlet types	NEMA L6-20R, NEMA L6-30R
Power plug	NEMA L6-30P
AC outlets quantity	4 AC-uitgang(en)
USB port	Y
Serial interface	Y
Serial interface type	RJ-45
Serial ports quantity	1
Ethernet LAN (RJ-45) ports	1
Cabling technology	10/100Base-T
Emergency Power Off (EPO) connector	Y
SmartSlot	Y
Battery
Battery technology	Sealed Lead Acid (VRLA)
Battery capacity	840 VAh
Battery voltage	192 V
Battery life (max)	5 jaar
Battery recharge time	1.5 uur
Hot-swap battery	Y
Automatic battery test	Y
Cold start	Y
Design
Form factor	Rackmount/Tower
Product colour	Black
Rack capacity	3U
LED indicators	Alarm, Status
International Protection (IP) code	IP20
Display type	LCD
Certification	CSA C22.2 No.107.3-05, FCC Part 15 Class A, NOM, OSHPD, UL 1778
Operational conditions
Operating temperature (T-T)	0 - 40 °C
Storage temperature (T-T)	-15 - 45 °C
Operating relative humidity (H-H)	0 - 95 procent
Storage relative humidity (H-H)	0 - 95 procent
Operating altitude	0 - 3000 m
Non-operating altitude	0 - 15000 m
Packaging data
Package width	610 mm
Package depth	960 mm
Package height	330 mm
Package weight	68040 g
Weight & dimensions
Width	432 mm
Depth	719 mm
Height	130 mm
Weight	55790 g
Logistics data
Quantity per pallet	6 stuk(s)
