Smart. Versatile. Scaled for Modern Business.
Powered by the latest Intel Core Series 3 processor and boasting up to 40 Total Platform TOPS, ASUS NUC 16 is built for multitasking, smooth media processing, and everyday Copilot AI experiences.

Specification

Product
Product id	1031378
Brand	AsusTek
Partnr	90AS00T1-M001S0
EAN/UPC code	4711636778022
Warranty (months)	36 months
Processor
Processor manufacturer	Intel
Processor family	Intel Core 5
Processor generation	Intel Core (Series 3)
Processor model	315
Processor cores	6
Low Power Efficient-cores	4
Processor boost frequency	4.4 GHz
Performance cores	2
Low Power Efficient-core Max Turbo Frequency	3.6 GHz
Processor socket	FCBGA1516
Low Power Efficient-core Base Frequency	1400 MHz
Processor cache	6 MB
Processor cache type	Smart Cache
Performance-core base frequency	1.5 GHz
Processor threads	6
Performance-core Max Turbo Frequency	4.4 GHz
Processor base power	15 W
Maximum turbo power	35 W
Memory
Internal memory	16 GB
Internal memory type	DDR5-SDRAM
Maximum internal memory	128 GB
Memory slots	2x SO-DIMM
Neural processor unit (NPU)
Neural processor unit (NPU)	Intel AI Boost
Sparsity support	Y
Windows Studio effects support	Y
AI software frameworks supported by NPU	OpenVINO, Windows ML, ONNX RT, WebNN
NPU performance up to	15 TOPs
GPU performance up to	18 TOPs
Storage
Total storage capacity	512 GB
Optical drive type	N
Storage media	SSD
Number of storage drives installed	1
Total SSDs capacity	512 GB
Number of SSDs installed	1
SSD capacity	512 GB
SSD interface	PCI Express 4.0
NVMe	Y
SSD form factor	M.2
Graphics
Discrete graphics adapter	N
On-board graphics adapter	Y
Discrete graphics adapter model	Not available
On-board graphics adapter family	Intel Graphics
On-board GPU manufacturer	Intel
On-board graphics adapter model	Intel Graphics
Network
Ethernet LAN	Y
Ethernet LAN data rates	2500 Mbit/s
Wi-Fi	Y
Top Wi-Fi standard	Wi-Fi 7 (802.11be)
WLAN controller manufacturer	Intel
Wi-Fi standards	Wi-Fi 7 (802.11be)
WLAN controller model	Intel Wi-Fi 7 BE211
Bluetooth	Y
Bluetooth version	6.0
Ports & interfaces
USB 2.0 ports quantity	2
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity	2
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity	1
Intel® Thunderbolt 4	Y
Thunderbolt 4 ports quantity	1
HDMI ports quantity	2
HDMI version	2.1
Ethernet LAN (RJ-45) ports	2
Design
Chassis type	Mini PC
Colour name	Black
Cable lock slot	Y
Cable lock slot type	Kensington
Product colour	Black
Introduction year	2026
Performance
Product type	Mini PC (<= 3L)
Market positioning	Home & Office
Software
Operating system installed	Windows 11 Pro
Operating system architecture	64-bit
Power
Power supply	90 W
Weight & dimensions
Width	144 mm
Depth	117 mm
Height	42 mm
Weight	585.6 g
Package width	183 mm
Package depth	151 mm
Package height	127 mm
Package weight	1402 g
Packaging content
Display included	N
