Product |
Product id
| 952151
|
Brand
| AsusTek
|
Partnr
| 90IG08V0-MO3N0V
|
EAN/UPC code
| 4711387335680
|
Warranty (months)
| 24 months
|
WAN connection |
Ethernet WAN
| Y
|
SIM card slot
| N
|
3G/4G USB modem compatibility
| Y
|
WAN connection type
| RJ-45
|
Wireless LAN features |
Wi-Fi band
| Dual-band (2.4 GHz / 5 GHz)
|
Top Wi-Fi standard
| Wi-Fi 7 (802.11be)
|
WLAN data transfer rate (max)
| 5764 Mbit/s
|
Wi-Fi standards
| 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax), Wi-Fi 6E (802.11ax), Wi-Fi 7 (802.11be)
|
WLAN data transfer rate (first band)
| 1376 Mbit/s
|
WLAN data transfer rate (second band)
| 5764 Mbit/s
|
Modulation
| 4096-QAM, OFDMA
|
Network |
Ethernet LAN
| Y
|
Ethernet LAN interface type
| 10 Gigabit Ethernet
|
Ethernet LAN data rates
| 1000, 2500, 10000 Mbit/s
|
Port forwarding
| Y
|
Port triggering
| Y
|
Dynamic DNS (DDNS)
| Y
|
Built-in FTP server
| Y
|
Support Samba (storage)
| Y
|
VPN support
| nstant Guard
VPN Client L2TP
VPN Client Open VPN
VPN Client PPTP
VPN Client WireGuard
VPN Server IPSec
VPN Server Open VPN
VPN Server PPTP
VPN Server WireGuard
VPN Fusion
Support Surfshark
|
Media server
| Y
|
Ports & interfaces |
Ethernet LAN (RJ-45) ports
| 9
|
USB port
| Y
|
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
| 1
|
Fiber optic connector
| SFP+
|
Management features |
Bandwidth control
| Y
|
Quality of Service (QoS) support
| Y
|
Wake-on-LAN ready
| Y
|
Reset button
| Y
|
WPS push button
| Y
|
MU-MIMO technology
| Y
|
Security |
Security algorithms
| SSH, WPA, WPA-Enterprise, WPA-Personal, WPA2-Enterprise, WPA2-Personal, WPA3-Enterprise, WPA3-Personal, WPS
|
Firewall
| Y
|
Firewall security
| Maximum Firewall Keyword Filter : 64 • Maximum Firewall Network Service Filter : 32 • Maximum Firewall URL Filter : 64
|
Parental control
| Y
|
MAC address filtering
| Y
|
System event log
| Y
|
DMZ support
| Y
|
Network address translation (NAT)
| Y
|
NAT functionality
| • PPTP Pass-Through
• L2TP Pass-Through
• IPSec Pass-Through
• RTSP Pass-Through
• H.323 Pass-Through
• SIP Pass-Through
• PPPoE Relay
|
Protocols |
DHCP server
| Y
|
Design |
Product type
| Tabletop router
|
Product colour
| Black, Grey
|
LED indicators
| LAN, Power, USB, WAN
|
On/off switch
| Y
|
Antenna |
Antenna design
| External
|
Antennas quantity
| 4
|
Features |
Built-in processor
| Y
|
Processor frequency
| 2600 MHz
|
Processor cores
| 4
|
Internal memory
| 2000 MB
|
Flash memory
| 256 MB
|
Power |
Power source type
| AC
|
AC input voltage
| 110 - 240 V
|
AC input frequency
| 50/60 Hz
|
Output voltage
| 19 V
|
Output current
| 2.37 A
|
Weight & dimensions |
Width
| 300 mm
|
Depth
| 188 mm
|
Height
| 60.5 mm
|
Weight
| 1060 g
|
Packaging data |
Cables included
| LAN (RJ-45), RJ-9
|
AC adapter included
| Y
|
Warranty card
| Y
|
Quick start guide
| Y
|
