ASUS ZenWiFi BD4 Outdoor
Worry-Free WiFi, Indoors and Out
Powered by WiFi 7 and next-gen AiMesh technology, the ASUS ZenWiFi BD4 Outdoor router delivers blazing-fast speeds up to 3600 Mbps, helping ensure seamless and reliable WiFi from your backyard to every corner of your home. IP65 water-resistance and flexible mounting options make it ideal for outdoor installation in a variety of settings. Dual 2.5G PoE ports further streamline setup by eliminating the need for an electrical outlet. In addition, a suite of advanced network security features and Smart Home Master SSIDs deliver premium protection and effortless control for your connected devices.

Specification

Product
Product id	1006164
Brand	AsusTek
Partnr	90IG09A0-MO3B60
EAN/UPC code	4711387611876
Warranty (months)	24 months
Design
LED indicators	Power
Product colour	White
Product type	Mesh router
Antenna type	Internal
Antennas quantity	2
Reset button	Y
Maximum coverage	235 m²
Wireless LAN features
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Top Wi-Fi standard	Wi-Fi 7 (802.11be)
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax), Wi-Fi 7 (802.11be)
Security algorithms	WPA-Enterprise, WPA-Personal, WPA2-Enterprise, WPA2-Personal, WPA3-Personal, WPS
WLAN data transfer rate (max)	3600 Mbit/s
WLAN data transfer rate (first band)	688 Mbit/s
WLAN data transfer rate (second band)	2882 Mbit/s
IGMP snooping	Y
Dynamic DNS (DDNS)	Y
VPN support	Instant Guard VPN Client L2TP VPN Client Open VPN VPN Client PPTP VPN Client WireGuard VPN Server IPSec VPN Server Open VPN VPN Server PPTP VPN Server WireGuard VPN Fusion
Features
Processor cores	4
Built-in processor	Y
Processor frequency	1.5 GHz
Internal memory	512 MB
Flash memory	128 MB
Quality of Service (QoS) support	Y
Port forwarding	Y
Firewall security	Firewall
BeamForming	Y
Virtual assistant	Google Assistant
Parental control	Y
Parental control features	Content filter, SafeSearch, Time rewards
MU-MIMO technology	Y
Protocols
DHCP server	Y
Ports & interfaces
Ethernet LAN (RJ-45) ports	2
Ethernet WAN	Y
Power
AC input voltage	110 - 240 V
AC adapter output voltage	12 V
AC adapter output current	2 A
AC input frequency	50 - 60 Hz
Weight & dimensions
Width	106 mm
Depth	106 mm
Height	200 mm
Weight	1040 g
Package width	250 mm
Package depth	246 mm
Package height	134 mm
Package weight	1840 g
Packaging content
Number of products included	1 stuk(s)
Ethernet cable	Y
Quick installation guide	Y
