| Product |
| Product id |
1027234 |
| Brand |
AsusTek |
| Partnr |
90IG0AE0-MO9C00 |
| EAN/UPC code |
4711636172417 |
| Warranty (months) |
36 months |
| WAN connection |
| Ethernet WAN |
Y |
| SIM card slot |
N |
| 3G/4G USB modem compatibility |
N |
| WAN connection type |
RJ-45 |
| Wireless LAN features |
| Wi-Fi band |
Dual-band (2.4 GHz / 5 GHz) |
| Top Wi-Fi standard |
Wi-Fi 7 (802.11be) |
| WLAN data transfer rate (max) |
5000 Mbit/s |
| Wi-Fi standards |
802.11a, Wi-Fi 5 (802.11ac), Wi-Fi 7 (802.11be), 802.11b, Wi-Fi 6 (802.11ax), 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 6E (802.11ax) |
| WLAN data transfer rate (first band) |
688 Mbit/s |
| WLAN data transfer rate (second band) |
4320 Mbit/s |
| Modulation |
4096-QAM |
| Network |
| Ethernet LAN |
Y |
| Ethernet LAN interface type |
2.5 Gigabit Ethernet |
| Ethernet LAN data rates |
1000, 2500 Mbit/s |
| Port forwarding |
Y |
| Port triggering |
Y |
| Ports & interfaces |
| Ethernet LAN (RJ-45) ports |
5 |
| USB port |
N |
| Management features |
| Reset button |
Y |
| WPS push button |
Y |
| MU-MIMO technology |
Y |
| Security |
| Parental control |
Y |
| MAC address filtering |
Y |
| System event log |
Y |
| Protocols |
| DHCP server |
Y |
| Design |
| Product type |
Tabletop router |
| Product colour |
Black |
| LED indicators |
Power, LAN, WAN |
| On/off switch |
Y |
| Antenna |
| Antenna design |
Internal & external |
| Antennas quantity |
5 |
| Features |
| Built-in processor |
Y |
| Processor frequency |
2000 MHz |
| Processor cores |
4 |
| Internal memory |
1000 MB |
| Flash memory |
128 MB |
| Firmware upgradeable |
Y |
| Power |
| Power source type |
AC |
| AC input voltage |
100 - 240 V |
| AC input frequency |
50/60 Hz |
| Output voltage |
12 V |
| Output current |
2 A |
| Operational conditions |
| Operating temperature (T-T) |
0 - 40 °C |
| Storage temperature (T-T) |
0 - 70 °C |
| Operating relative humidity (H-H) |
50 - 90 procent |
| Storage relative humidity (H-H) |
20 - 90 procent |
| Weight & dimensions |
| Width |
238 mm |
| Depth |
193 mm |
| Height |
59 mm |
| Weight |
506 g |
| Package width |
285 mm |
| Package depth |
193 mm |
| Package height |
104 mm |
| Package weight |
1060 g |
| Packaging data |
| Cables included |
LAN (RJ-45) |
| AC adapter included |
Y |
| Quick start guide |
Y |
| Package type |
Box |
