Intel Xeon E-2400 processors/Intel Xeon 6300 processors
Designed for small- to medium-sized businesses (SMBs) and cloud-service providers, offering robust and secure solutions. These processors support up to eight cores and 16 threads, with a maximum frequency of 5.6 GHz and a 95 W TDP, ensuring rapid data processing and application responsiveness. They support up to 128 GB of DDR5 4400 MT/s memory (Intel Xeon E-2400) or up to 4800 MT/s memory (Intel Xeon 6300) and PCIe 5.0 interfaces, providing server-grade 24/7 reliability for business-critical services and customer data, and cost-effective performance for entry-level bare-metal cloud services.

Specification

Product
Product id	998874
Brand	AsusTek
Partnr	90SF03A1-M00070
EAN/UPC code	4711387500378
Processor
Processor socket	LGA 1700
Number of processors supported	1
Intel Xeon series	6300
Memory
Number of DIMM slots	4
Supported memory types	DDR5-SDRAM
Supported DIMM module capacities	8GB, 16GB, 32GB
Maximum internal memory	128 GB
Supported RDIMM clock speeds	4400, 4000, 3600 MHz
Memory channels	Dual-channel
Storage
Number of storage drives supported	8
Hot-swap HDD bays	Y
Number of 3.5" bays	4
Storage drive sizes supported	3.5 "
Supported storage drive types	HDD & SSD
Supported storage drive interfaces	M.2, Serial ATA III, Serial Attached SCSI (SAS)
Network
Ethernet LAN	Y
Ports & interfaces
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	2
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity	3
Ethernet LAN (RJ-45) ports	1
VGA (D-Sub) ports quantity	1
COM ports quantity	1
Number of SATA III connectors	8
Expansion slots
PCI Express x16 (Gen 5. x) slots	1
Design
Chassis type	Rack (1U)
Product colour	Silver
LED indicators	Power, Reset, HDD
Power
Power supply	450 W
80 PLUS certification	80 PLUS Platinum
Operational conditions
Operating temperature (T-T)	10 - 35 °C
Storage temperature (T-T)	-40 - 70 °C
Storage relative humidity (H-H)	20 - 90 procent
Weight & dimensions
Width	497 mm
Depth	439.5 mm
Height	44 mm
Weight	15200 g
