Prime Performance
With 80+ Bronze certification, dual ball fan bearings, etched cables and an 6-year warranty, the ASUS Prime series PSU brings efficient and durable power delivery to reliable performance for the system build.

Specification

Product
Product id	1005343
Brand	AsusTek
Partnr	90YE00Y1-B0NA00
EAN/UPC code	4711387635285
Warranty (months)	6-year warranty included.
Endurance
Mean time between failures (MTBF)	120000 uur
Power
Total power	650 W
AC input voltage	100 - 240 V
Power Factor Correction (PFC) type	Active
Combined power (+3.3V)	110 W
Combined power (+12V)	648 W
Combined power (+5V)	110 W
Combined power (-12V)	3.6 W
Combined power (+5Vsb)	12.5 W
Max output current (+3.3V)	20 A
Max output current (+12V)	54 A
Max output current (+5V)	20 A
Max output current (-12V)	0.3 A
Max output current (+5Vsb)	2.5 A
Power protection features	Over current, Over power, Over voltage, Overheating, Short circuit, Under voltage
Ports & interfaces
Motherboard power connector	20+4 pin ATX
Number of SATA power connectors	5
SATA power cable length	120, 400 mm
Peripheral (Molex) power connectors (4-pin)	3
Peripheral (Molex) power cable length	120, 400 mm
PCI Express power connectors (8-pin)	2
PCI Express power cable length	600 mm
CPU power connector (4+4 pin)	Y
CPU power cable length	800 mm
Cabling type	Fully-Modular
Performance
Purpose	PC
Power supply unit (PSU) form factor	ATX
80 PLUS certification	80 PLUS Bronze
Bearing technology	DBB
Design
Product colour	Black
Cooling type	Active
Fan diameter	135 mm
Technical details
Compliance certificates	RoHS
Weight & dimensions
Width	150 mm
Depth	150 mm
Height	86 mm
Weight	2200 g
Packaging data
Cables included	AC, CPU, PCIe, Peripheral (Molex), SATA
Package width	340 mm
Package depth	196 mm
Package height	115 mm
Package weight	3000 g
Package type	Box
