Allied Telesis AT-2911 Series Network Interface Cards feature a PCI Express (PCIe x1) design, providing the maximum possible bandwidth and bus efficiency while providing the benefits of low power consumption.

High Reliability
The AT-2911 Series Gigabit interface comes with a comprehensive Microsoft Windows utility which performs detailed tests, diagnostics and analysis.

Advanced Manageability
The priority queuing offered by the AT-2911 Series can help users set up the network based on their own needs. The comprehensive diagnostics and configuration software suite provides system administrators and engineers with a profound tool to analyze the interface card and check specific data.

Specification

Product
Product id	665624
Brand	Allied Telesis
Partnr	AT-2911SX/SC-901
EAN/UPC code	767035196619
Technical details
Sustainability certificates	RoHS
Ports & interfaces
Connectivity technology	Wired
Host interface	PCI Express
Interface	Fiber
Fiber optic connector	SC
Fiber ports quantity	1
Network
Maximum data transfer rate	1000 Mbit/s
Networking standards	IEEE 802.1p, IEEE 802.1Q, IEEE 802.2, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ac, IEEE 802.3ad, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Fiber ethernet cabling technology	1000BASE‑ZX
Jumbo frames support	Y
Quality of Service (QoS) support	Y
Design
Internal	Y
LED indicators	Y
Certification	UL FCC/EN55022 A TUV EN55024 CE C-TICK VCCI
Power
Output voltage	3.3 V
Power consumption (typical)	9.2 W
Operational conditions
Operating temperature (T-T)	0 - 40 °C
Storage temperature (T-T)	-25 - 70 °C
Operating relative humidity (H-H)	5 - 90 procent
System requirements
Windows operating systems supported	Y
Linux operating systems supported	Y
Weight & dimensions
Width	87 mm
Height	56 mm
Weight	700 g
Other features
Flow control support	Y
Link/Act LED	Y
Management protocols	SNMP
