The CL1000 is a LCD KVM console that serves as the front-end for standard KVM switches. The CL1000 features an integrated 17" or 19" LED-backlit LCD panel, full keyboard, and touchpad in a 1U, rack-mountable, Slideaway™ housing.
1x CL1000M or CL1000N with Standard Rack Mount Kit
1x 2L-5202UP Custom KVM Cable (VGA, USB; 1.8m/6ft)
1x LIN2-418K-E12G Power Cord
1x User Instructions

Specification

Product
Product id	987563
Brand	Aten
Partnr	CL1000N-ATA-AG
EAN/UPC code	4710469345357
Display
Display diagonal	19 inch
Display	LCD
Technical details
LED indicators	Y
Number of computers controlled	1
Rack mounting	Y
Push button	Y
Product colour	Black
Operating relative humidity (H-H)	0 - 80 procent
Rack capacity	1U
Maximum resolution	1280 x 1024 Pixels
Ports & interfaces
VGA (D-Sub) ports quantity	1
Video port type	VGA
Mouse port type	PS/2
Keyboard port type	PS/2
Keyboard
Keyboard language	US English
Keyboard layout	QWERTY
Operational conditions
Operating temperature (T-T)	0 - 50 °C
Storage temperature (T-T)	-20 - 60 °C
Power
Power consumption (typical)	24 W
Input current	1 A
Weight & dimensions
Width	483 mm
Height	44 mm
Depth	585.2 mm
Weight	11550 g
Packaging data
Package weight	14250 g
Package width	668 mm
Package depth	718 mm
Package height	135 mm
Packaging content
Cables included	KVM
Manual	Y
Rack mount kit	Y
AC adapter included	Y
Logistics data
Master (outer) case width	668 mm
Master (outer) case net weight	11550 g
Master (outer) case length	718 mm
Master (outer) case height	135 mm
Quantity per master (outer) case	1 stuk(s)
Master (outer) case weight	14250 g
