18-Outlet 1U Extended Depth Basic PDU with Surge Protection (10A) (18x C13)


Not in stock
€ 93,52
€ 113,15 incl 21% VAT
ATEN's Basic PDU family is extended with 1U members containing 18 outlets and available in IEC or NEMA socket configurations. The compact aluminum housing gives a sleek, yet robust look while minimizing installation space for work space efficiency. Thanks to the built-in surge protection module, the IT devices connected to the PDU are well-protected from sudden surges in electricity; plus, the equipment downtime is reduced as a result of the overcurrent protection design. The Basic PDUs are tailored made for individuals who are in need of industrial-grade, easy-to-deploy power distribution unit in data centers, server rooms, and network wiring closets.
1x power distribution unit
1x power cord
1x user instructions


Product id 789346
Brand Aten
Partnr PE0118SG-AT-G
EAN/UPC code 4719264648908
PDU types Basic
Rack capacity 1U
Housing material Aluminium
Ports & interfaces
AC outlets quantity 18 AC-uitgang(en)
Power plug IEC 320
AC outlet types C13 coupler
Surge protection Y
AC input frequency 50-60 Hz
Maximum current 10 A
Block 1 output current 10 A
Load capacity 2400 VA
Block 2 output current 10 A
Weight & dimensions
Width 44.4 mm
Depth 482 mm
Height 88.5 mm
Weight 1890 g
Package weight 2250 g
Packaging data
Package width 123 mm
Package depth 696 mm
Package height 150 mm
Technical details
Nominal input voltage 100-240 V
Product colour Black
Operational conditions
Operating temperature (T-T) 0 - 40 °C
Storage temperature (T-T) -20 - 60 °C
Logistics data
Master (outer) case net weight 18900 g
Master (outer) case width 650 mm
Master (outer) case length 710 mm
Master (outer) case height 322 mm
Master (outer) case weight 22500 g
Quantity per master (outer) case 10 stuk(s)
