Engineered to be an intelligent power distribution solution, the PE4102G Eco PDU Power Controller ships with 2 power outlets in an IEC socket configuration. It provides secure, centralized, intelligent, and remote power management of data center IT equipment to minimize operating costs.

The PE4102G features the remote power control function, allowing you to control devices attached to the PDU at the PDU device level from practically any location via a TCP/IP connection. The power sequence design eliminates the risks of power inrush, guaranteeing reliable operation and protecting the overall system health. With the support for eco DC software, it provides an easy method for managing multiple devices, offering an intuitive and user-friendly Graphical User Interface that allows you to configure a PDU device and reboot the device in case any equipment lock-up occurs. Additionally, the auto ping and auto reboot functions ensure devices remain responsive by automatically detecting connection issues and rebooting when necessary. Administrators can switch on/off or set a delay time for each power outlet or individual power outlet group whenever, wherever.

The PE4102G boasts a slim, compact form factor and supports desk mount, wall mount, as well as rack mount, ensuring easy installation in confined spaces. It is a smart eco PDU power controller tailored for hospitality or retail applications, such as digital signage and video walls, for edge computing devices, including routers, servers, and cameras, or for any data center environments where there is no need to keep the servers powered on at all times.

Specification

Product
Product id	1013032
Brand	Aten
Partnr	PE4102G-AT-G
EAN/UPC code	4711581520691
Design
PDU types	Managed
Rack mounting	Y
Mounting type	Desk/Wall
Ports & interfaces
AC outlets quantity	2 AC-uitgang(en)
Power plug	C14 coupler
AC outlet types	C13 coupler
Ethernet LAN (RJ-45) ports	1
Cables included	AC
Features
Password protection	Y
Management features
Supported network protocols	TCP/IP, UDP, HTTP, HTTPS, SSL, SMTP, ARP, NTP, DNS, SNMP V1&V2&V3
Power
Nominal output voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Maximum current	10 A
Load capacity	2400 VA
Weight & dimensions
Width	127.8 mm
Depth	170 mm
Height	44 mm
Weight	980 g
Package weight	1275 g
Packaging data
Package width	95 mm
Package depth	265 mm
Package height	220 mm
Package volume	5550.101932032 cm³
Packaging content
Manual	Y
Technical details
Nominal input voltage	100 - 240 V
Cable length	3 m
Compliance certificates	Low Voltage Directive (LVD), CE, Electromagnetic Compatibility (EMC)
Product colour	Black
Operational conditions
Operating temperature (T-T)	0 - 50 °C
Storage temperature (T-T)	-20 - 60 °C
Operating relative humidity (H-H)	0 - 80 procent
Logistics data
Country of origin	China
Master (outer) case net weight	4900 g
Master (outer) case width	232 mm
Master (outer) case length	500 mm
Master (outer) case height	283 mm
Master (outer) case weight	6920 g
Master (outer) case volume	32819.225200128 cm³
