| Product |
| Product id |
1011360 |
| Brand |
Be Quiet! |
| Partnr |
BK024 |
| EAN/UPC code |
4260052187319 |
| Warranty (months) |
3-year manufacturer’s warranty |
| Performance |
| Suitable for rooms |
Processor |
| Type |
Cooler |
| Fan diameter |
120 mm |
| Supported processor sockets |
LGA 1150 (Socket H3), LGA 1151 (Socket H4), LGA 1155 (Socket H2), LGA 1200 (Socket H5), LGA 1700, LGA 2011 (Socket R), LGA 2011-v3 (Socket R), LGA 2066, Socket AM4, Socket AM5 |
| Rotational speed (max) |
1500 RPM |
| Noise level (low speed) |
11 dB |
| Noise level (high speed) |
23.6 dB |
| Pulse-width modulation (PWM) support |
Y |
| Bearing type |
Fluid Dynamic Bearing (FDB) |
| Design |
| Product colour |
Black |
| Base plate material |
Copper |
| Number of fans |
1 ventilator(en) |
| Number of fins |
51 |
| Fins material |
Aluminium |
| Number of heat pipes |
4 |
| Fan connector |
4-pin |
| Certification |
CE |
| Technical details |
| Compliance certificates |
RoHS |
| Power |
| Power consumption (typical) |
0.96 W |
| Rated voltage |
12 V |
| Rated current |
0.08 A |
| Thermal Design Power (TDP) |
180 W |
| Weight & dimensions |
| Width |
127 mm |
| Depth |
72 mm |
| Height |
159.4 mm |
| Weight |
620 g |
| Fan dimensions (W x D x H) |
120 x 120 x 23 mm |
| Heat pipes diameter |
6 mm |
| Cable length |
0.22 m |
| Package width |
190 mm |
| Package depth |
115 mm |
| Package height |
190 mm |
| Package weight |
993 g |
| Packaging content |
| Mounting kit |
Y |
| Manual |
Y |
| Other features |
| Harmonized System (HS) code |
84733080 |
| Thermal grease |
Y |
| Heatsink dimensions (W x D x H) |
127 x 47.4 x 159.4 mm |
| Logistics data |
| Master (outer) case width |
400 mm |
| Master (outer) case length |
475 mm |
| Master (outer) case height |
410 mm |
| Quantity per master (outer) case |
16 stuk(s) |
| Master (outer) case weight |
17200 g |
