High-quality, cost effective professional colour printing with premium results. Built for business, this device is designed to deliver enterprise level performance whilst providing a competitive total cost of ownership. With high-speed, glossy colour printing you can rely on combined with the flexibility to be tailored to your specific business needs. Together with:

- Integrated NFC reader
- Gigabit network as standard with optional 2.4/5GHz Wi-Fi module
- Expandable memory capacity (USB flash drive not included)
- Optional Mailbox and Staple Finisher
- Fully compatible with 3rd party print management and document management solutions including Kofax, YSoft and more

Solutions enabled out of the box

The HL-L9430CDN comes with Cloud Secure Print straight out the box, so you can securely print your documents directly from the cloud. You also have the option to further enhance your device with third party solutions, meaning that you can have a fully integrated print, capture and output management solution all from one provider.
Woman holding NFC card bext to printer, colour documents, table
Enterprise level security

The HL-L9430CDN has built-in industry security protocols to securely protect your network, documents and device. Additional levels of protection can be setup to restrict access to certain settings and functions available to authorised user.
Man holding colour A4 document with woman in office, buildings, glass window
Quality and performance

Impressive colour and high-quality outputs makes the HL-L9430CDN the device of choice for many businesses. The robust design and long life components provides complete peace of mind that you can keep on printing and scanning without interruption.
Printer on a tower tray with a mailbox against copper and black wall
Flexibility for your business

With a choice of a staple finisher to automatically staple your documents, to a mailbox, for sorting your printed documents - your printer can be easily transformed to help improve overall business productivity. Together with a selection of additional paper-trays, you can easily scale your HL-L9430CDN from a desktop to a floor-standing device.
A man and two women sat around table with colour documents on the table, printer, desks, chairs
Contract printing that looks after itself

Get the most out of your HL-L9430CDN with managed print services. Your business can easily manage and control print costs and have the high-yield toners you need, when they need them.

Specification

Product
Product id	942217
Brand	Brother
Partnr	HL-L9430CDN
EAN/UPC code	4977766813969
Packaging data
Package width	557 mm
Package depth	628.2 mm
Package height	633.5 mm
Package weight	34300 g
Printing
Colour	Y
Print technology	Laser
Duplex printing	Y
Duplex printing mode	Auto
Maximum resolution	2400 x 600 pixels
Print speed (colour, normal quality, A4/US Letter)	40 ppm
Duplex print speed (colour, normal quality, A4/US Letter)	28 ppm
Warm-up time	20 s
Time to first page (colour, normal)	10 s
Watermark printing	Y
Secure printing	Y
N-up printing	2, 4, 9, 16, 25
Booklet printing function	Y
Features
Maximum duty cycle	120000 pagina's per maand
Recommended duty cycle	0 - 12000 pagina's per maand
Printing colours	Black, Cyan, Magenta, Yellow
Page description languages	BR-Script 3, PCL 5c, PCL 5e, PCL 6, PDF 1.7, XPS
Input & output capacity
Total number of input trays	1
Total input capacity	520 vel
Total output capacity	250 vel
Multi-Purpose tray	Y
Multi-Purpose tray input capacity	100 vel
Maximum input capacity	2600 vel
Paper handling
Maximum ISO A-series paper size	A4
Paper tray media types	Bond paper, Envelopes, Glossy paper, Plain paper, Recycled paper, Thick paper, Thicker paper, Thin paper
ISO A-series sizes (A0. . . A9)	A4, A5, A6
ISO B-series sizes (B0. . . B9)	B5, B6
Envelopes sizes	C5, Com-10, DL
Custom media width	76.2 - 215.9 mm
Custom media length	127 - 355.6 mm
Paper tray media weight	64 - 105 g/m²
Multi-Purpose Tray media weight	60 - 230 g/m²
Auto Document Feeder (ADF) media weight	60 - 230 g/m²
Ports & interfaces
Direct printing	Y
USB port	Y
USB 2.0 ports quantity	1
Network
Wi-Fi	N
Ethernet LAN	Y
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Cabling technology	10/100/1000Base-T(X)
Wi-Fi standards	802.11a, 802.11g, Wi-Fi 4 (802.11n)
Near Field Communication (NFC)	Y
Security algorithms	802.1x RADIUS, APOP, EAP-FAST, EAP-MD5, EAP-TLS, EAP-TTLS, HTTPS, IPPS, PEAP, SMTP-AUTH, SNMPv3, SSL/TLS, WPA-PSK, WPA2-PSK, WPA3-SAE
Supported network protocols (IPv4)	ARP, RARP, BOOTP, DHCP, APIPA(Auto IP), WINS/NetBIOS name resolution, DNS Resolver, mDNS, LLMNR responder, LPR/LPD, Custom Raw Port/ Port9100, IPP/IPPS, FTP Server, TELNET Server, HTTP/HTTPS server, TFTP client and server, SMTP Client, SNMPv1/v2c/ v3, ICMP, Web Services (Print), CIFS client, SNTP client, LDAP
Supported network protocols (IPv6)	NDP, RA, DNS resolver, mDNS, LLMNR responder, LPR/LPD, Custom Raw Port/Port9100, IPP/IPPS, FTP Server, TELNET Server, HTTP/HTTPS server, TFTP client and server, SMTP Client, SNMPv1/v2c/v3, ICMPv6, Web Services (Print), CIFS Client, SNTP Client, LDAP
Mobile printing technologies	Apple AirPrint, Brother iPrint & Scan, Mopria Print Service
Performance
Internal memory	1024 MB
Sound pressure level (printing)	56.5 dB
Sound pressure level (quiet mode)	53 dB
Sound power level (printing)	68.8 dB
Design
Market positioning	Home & Office
Product colour	White
Built-in display	Y
Display	LCD
Colour display	Y
Display diagonal	3.5 inch
Control type	Touch
Power
Power consumption (printing)	770 W
Power consumption (ready)	85 W
Power consumption (off)	0.04 W
Energy Star Typical Electricity Consumption (TEC)	0.662 kWh/week
AC input voltage	220 - 240 V
AC input frequency	50/60 Hz
System requirements
Windows operating systems supported	Windows 10, Windows 7, Windows 8
Mac operating systems supported	Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina, Mac OS X 10.15.3 Catalina
Linux operating systems supported	Y
Server operating systems supported	Windows Server 2008, Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2, Windows Server 2016, Windows Server 2019
Other operating systems supported	ChromeOS
Operational conditions
Operating temperature (T-T)	10 - 32 °C
Storage temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	20 - 80 procent
Storage relative humidity (H-H)	10 - 90 procent
Weight & dimensions
Width	442 mm
Depth	541 mm
Height	403 mm
Weight	29000 g
Packaging content
Cartridge(s) included	Y
Included cartridge capacity (black)	9000 pagina's
Included cartridge capacity (CMY)	5000 pagina's
