Canon Ultra-Wide RF 10-20 mm F4L IS STM Camera Lenses for consistent exposures throughout the zoom range, for photo and video so you can take it with you more often. Optimised, smooth, near-silent focusing for stills and video. Peripheral Coordinated Control IS stabilises photos and video – right to the corners of the frame. Glass moulded aspherical elements plus three UD elements and a Super UD element for superb quality. Use ND filters for video work and long exposures. Ergonomic, for instinctive shooting. Specifications: Image Size: Full Frame, Angle of View (Horizontal, vertical, diagonal), : 121 degrees 55′- 84 degrees, 100 degrees 25′ - 62 degrees, 130 degrees 25′- 94 degrees, Lens Construction (Elements/Groups) : 16/12, Special Optics: 1x SUD, 3x UD, 3x Gmo Apherical (1 element both UD/Aspherical), Number of Diaphragm Blades: 9, Minimum Aperture: 22, Closest Focusing Distance (m): 0.25, Maximum Magnification (x): 0.12 (at 20mm), 0.06 ( at 10mm), Control Ring: Yes, Image Stabilizer OIS1: 5, Image Stabilizer IBIS x OIS2: 6, AF Actuator: STM, Coatings: ASC, Super Spectra, SWC, Fluorine: Front, Lens Cap: Lens Cap 10-20, Lens Case/Pouch: LP1219, Rear End Cap: Lens Dust Cap RF, Extender Compatibility: Not Compatible, Dust/Moisture Resistance: Yes3, Filter Diameter (mm): Rear-mounted gelatine filter (35x20mm), Max. Diameter x Length (mm)4: 83.7 x 112, Weight (g): 570g.

Specification

Product
Product id	978188
Brand	Canon
Partnr	6182C005
EAN/UPC code	4549292220582
Warranty (months)	2 Years
Performance
Auto focus	Y
Manual focus	Y
Lens coating features	Subwavelength Structure Coating (SWC), Super Spectra Coating (SSC)
Camera brands compatibility	Canon
Circular aperture	Y
Lens hood	Y
Lens colour	Black
AF actuator	STM
Number of Ultra-low Dispersion (UD) elements	1
Lens hood type	Built-in lens hood
Design
Mounting type	Bayonet
Dustproof	Y
Weatherproof	Y
Logistics data
Country of origin	Japan
Quantity per pack	1 stuk(s)
Number of layers per pallet	4
Number of cartons per pallet layer	4
Colour
Product colour	Black
Packaging content
Bag included	Y
Bag model	LP1219
Lens cap included	Y
Lens cap model	10-20
Rear lens cap included	Y
Rear lens cap model	RF
User guide	Y
Lens system
Component for	MILC
Lens structure (elements/groups)	16/12
Lens type	Wide zoom lens
Lens viewing angle, horizontal	121° 55' - 84° °
Focus adjustment	Auto/Manual
Focal length range	10 - 20 mm
Lens viewing angle, vertical	100° 25' - 62° °
Number of aspheric elements	3
Lens viewing angle, diagonal	130° 25' - 94° °
Image sensor format	Full frame
Image stabilizer	Y
Maximum aperture number	4
Closest focusing distance	0.25 m
Teleconverter/Extender compatible	N
Number of diaphragm blades	9
Minimum aperture number	22
Control ring	Y
Lens mount interface	Canon RF
Zoom capability	Y
Macro ratio	1:8.33
Image stabilizer type	Optical Image Stabilization (OIS)
Image stabilizer number of stops	5
Image stabilizer number of stops (OIS)	5
Image stabilizer number of stops (IBIS x OIS)	6
Weight & dimensions
Diameter	83.7 mm
Length	112 mm
Weight	570 g
Packaging data
Package width	250 mm
Package depth	250 mm
Package height	200 mm
Package weight	750 g
Package type	Box
