Flexible architectural agility
Designed for architectural agility and flexibility to help data centers smoothly migrate to a software-designed data center.

Specification

Product
Product id	635003
Brand	Dell
Partnr	210-APEX
EAN/UPC code	5397184223130
Warranty (months)	1 Year Return to Depot
Data transmission
MAC address table	16000 entries
Switching capacity	2000 Gbit/s
Packet buffer memory	32 MB
Network
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1Qaz, IEEE 802.1Qbb, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3ac, IEEE 802.3ad, IEEE 802.3x
10G support	Y
Port mirroring	Y
Address Resolution Protocol (ARP) entries (max)	128000
Link aggregation	Y
VLAN support	Y
Virtual LAN features	Tagged VLAN
Management features
Switch type	Managed
Switch layer	L2/L3
Quality of Service (QoS) support	Y
Protocols
Management protocols	CLI, SNMP, REST, API’s
Ports & interfaces
Basic switching RJ-45 Ethernet ports type	None
SFP module slots quantity	48
Fiber optic connector	QSFP-DD, QSFP28-DD, QSFP28, SFP28
Console port	RJ-45
Power connector	AC-in jack
Security
Security algorithms	802.1x RADIUS, AES, EAP
Weight & dimensions
Width	434 mm
Depth	460 mm
Height	44 mm
Weight	9700 g
Power
Power supply included	Y
Redundant power supply (RPS) support	Y
Number of power supply units	2
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (typical)	400 W
Power consumption (max)	602 W
Optical fiber
Switching optical modules type	100 Gigabit Ethernet
System requirements
Compatible operating systems	Debian Linux version 9
Multicast features
Multicast support	Y
Design
Rack mounting	Y
Stackable	Y
Form factor	1U
Product colour	Black
LED indicators	Y
Number of fans	4 ventilator(en)
Backlight display	Y
Display type	LED
Cable management	Y
Certification	RoHS
Operational conditions
Heat dissipation	2054 BTU/h
Storage temperature (T-T)	-40 - 70 °C
Storage relative humidity (H-H)	5 - 90 procent
Operating temperature (T-T)	0 - 45 °C
Operating relative humidity (H-H)	5 - 90 procent
Performance
Built-in processor	Y
Internal memory	16000 MB
List of RFCs	IP, IPv4, IPv6, RIP, OSPF, IS-IS, BGP
Minimum system requirements	Linux Kernel 4.9
Power over Ethernet (PoE)
Power over Ethernet (PoE)	N
