Flexible architectural agility
Designed for architectural agility and flexibility to help data centers smoothly migrate to a software-designed data center.

Specification

Product
Product id	658430
Brand	Dell
Partnr	210-APHQ
EAN/UPC code	5397184224403
Warranty (months)	1 Year Return to Depot
Data transmission
MAC address table	160000 entries
Switching capacity	2160 Gbit/s
Forwarding rate	1488 Mpps
Packet buffer memory	32 MB
Network
Networking standards	IEEE 802.3
10G support	Y
VLAN support	Y
Management features
Switch type	Managed
Switch layer	L2/L3
Quality of Service (QoS) support	Y
Protocols
Management protocols	CLI, SNMP, REST API’s
GARP VLAN Registration Protocol (GVRP)	Y
Ports & interfaces
Basic switching RJ-45 Ethernet ports type	None
Gigabit Ethernet (copper) ports quantity	1
SFP module slots quantity	24
QSFP+ module slots quantity	4
Console port	RJ-45/Micro-USB
USB 2.0 ports quantity	1
Power connector	AC-in jack
Weight & dimensions
Width	434 mm
Depth	460 mm
Height	43.6 mm
Power
Power supply included	Y
Redundant power supply (RPS) support	Y
Number of power supply units	2
AC input voltage	100 - 240 V
AC input frequency	50/60 Hz
Power consumption (max)	455 W
Power management	Y
System requirements
Compatible operating systems	OS10
Multicast features
Multicast support	Y
Design
Rack mounting	Y
Stackable	Y
Form factor	1U
Product colour	Black
Reset button	Y
LED indicators	Y
Airflow direction	Front-to-back airflow
Performance
Built-in processor	Y
Memory type	SDRAM
Internal memory	16000 MB
List of RFCs	IP, IPv4, IPv6, RIP, OSPF, IS-IS, BGP
Technical details
Sustainability certificates	RoHS
Power over Ethernet (PoE)
Power over Ethernet (PoE)	N
Other features
Latency	881
