The perfect blend of performance and density
Run the most popular IT applications easily with this air-cooled server that is the best choice for balanced and dense compute.

Specification

Product
Product id	1008246
Brand	Dell
Partnr	6WNX6
EAN/UPC code	5397184980606
Warranty (months)	3 Years Basic Onsite
Processor
Processor manufacturer	Intel
Processor family	Intel Xeon Silver
Processor model	4510
Processor frequency	2.4 GHz
Processor boost frequency	4.1 GHz
Processor cores	12
Processor cache	30 MB
Motherboard chipset	Intel C741
Number of processors installed	1
Thermal Design Power (TDP)	150 W
Processor threads	24
Memory clock speeds supported by processor	4400 MHz
Memory types supported by processor	DDR5-SDRAM
Memory
Internal memory	32 GB
Internal memory type	DDR5-SDRAM
Buffered memory type	Registered (buffered)
Memory ranking	2
Memory slots	16x DIMM
Memory data transfer rate	5600 MT/s
Maximum internal memory	1000 GB
Storage
Total storage capacity	480 GB
Number of SSDs installed	1
SSD capacity	480 GB
SSD interface	SATA III
SSD size	2.5" "
Number of SSDs supported	8
Supported SSD sizes	2.5"
Supported RAID controllers	Front PERC H755 Front Load
Hot-Plug support	Y
Optical drive type	N
Network
LAN controller	Broadcom 5720
Ethernet LAN	Y
Cabling technology	10/100/1000Base-T(X)
Ethernet interface type	Gigabit Ethernet
Ports & interfaces
Ethernet LAN (RJ-45) ports	2
USB 2.0 ports quantity	2
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	1
VGA (D-Sub) ports quantity	2
Expansion slots
PCI Express x16 (Gen 4. x) slots	1
PCI Express x8 (Gen 5. x) slots	1
Design
Chassis type	Rack (1U)
Product colour	Black
Rack rails	Y
Bezel	Y
Performance
Remote administration	iDRAC9, Enterprise 16G
Trusted Platform Module (TPM) version	2.0
Trusted Platform Module (TPM)	Y
Software
Operating system installed	N
Compatible operating systems	Canonical Ubuntu Server LTS Microsoft Windows Server with Hyper-V Red Hat Enterprise Linux SUSE Linux Enterprise Server VMware vSAN/ESXi
Power
Redundant power supply (RPS) support	Y
Power supply	1100 W
Number of redundant power supplies installed	2
Power supply input voltage	100-240
Operational conditions
Operating temperature (T-T)	10 - 35 °C
Storage temperature (T-T)	-40 - 65 °C
Storage relative humidity (H-H)	5 - 95 procent
Operating altitude	0 - 3048 m
Non-operating altitude	0 - 12000 m
Certificates
80 PLUS certification	80 PLUS Titanium
Weight & dimensions
Width	434 mm
Height	42.8 mm
Packaging content
Packaging content	ReadyRails A11 drop-in/stab-in Slide Combo Rails Without Cable Management Arm, Riser Config 5, Low Profile 2x Rack Power Cord 2M (C13/C14 12A) - FGA Only
Other features
Target workload	Read Intensive (RI)
Bytes per sector	512e
Data transfer rate	6 Gbit/s
Open Compute Project (OCP)	NIC 3.0
