1U value-optimized server for general-purpose IT
The Dell EMC PowerEdge R450, with 3rd generation Intel® Xeon® Scalable processors, offers improved performance and exceptional value in a 1U rack server.

Specification

Product
Product id	822751
Brand	Dell
Partnr	GPH2C
EAN/UPC code	5397184745625
Warranty (months)	3 Years Basic Onsite
Processor
Processor manufacturer	Intel
Processor family	Intel Xeon Silver
Processor model	4309Y
Processor frequency	2.8 GHz
Processor boost frequency	3.6 GHz
Processor generation	Intel Xeon Scalable 3rd Gen
Processor cache	12 MB
Number of processors installed	1
Memory
Internal memory	16 GB
Internal memory type	DDR4-SDRAM
Buffered memory type	Registered (buffered)
Memory ranking	2
Memory clock speed	2666 MHz
Memory slots	16x DIMM
Memory layout (slots x size)	1 x 16 GB
Memory data transfer rate	3200 MT/s
Storage
Total storage capacity	480 GB
Number of SSDs installed	1
SSD capacity	480 GB
SSD interface	SATA III
SSD size	2.5" "
Number of SSDs supported	8
Supported SSD sizes	2.5"
Supported RAID controllers	PERC H355
Hot-Plug support	Y
Optical drive type	N
Drive writes per day (DWPD)	1
Network
LAN controller	Broadcom 5720
Ethernet LAN	Y
Cabling technology	10/100/1000Base-T(X)
Ethernet interface type	Gigabit Ethernet
Ports & interfaces
Ethernet LAN (RJ-45) ports	2
USB 2.0 ports quantity	1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	3
VGA (D-Sub) ports quantity	2
Power cables quantity	1
Expansion slots
PCI Express x16 slots	2
Design
Chassis type	Rack (1U)
Product colour	Black
Bezel	Y
Performance
Remote administration	iDRAC9, Enterprise 15G
Harmonized System (HS) code	84714100
Software
Operating system installed	N
Compatible operating systems	Canonical Ubuntu Server LTS Citrix Hypervisor Microsoft Windows Server with Hyper-V Red Hat Enterprise Linux SUSE Linux Enterprise Server VMware ESXi
Power
Redundant power supply (RPS) support	Y
Power supply	800 W
Number of redundant power supplies supported	2
Number of main power supplies	1
Power cable length	2 m
Power cable connector 1	C13 coupler
Power cable connector 2	C14 coupler
Power cable current	10 A
Operational conditions
Operating temperature (T-T)	10 - 35 °C
Storage temperature (T-T)	-40 - 65 °C
Operating relative humidity (H-H)	8 - 80 procent
Storage relative humidity (H-H)	5 - 95 procent
Operating altitude	0 - 3048 m
Non-operating altitude	0 - 12000 m
Weight & dimensions
Width	482 mm
Height	42.8 mm
Other features
Bytes per sector	512
Data transfer rate	6 Gbit/s
