DELL Pro Max T2 FCT2250. Processor family: Intel Core Ultra 9, Processor model: 285. Internal memory: 32 GB, Internal memory type: DDR5-SDRAM. Total storage capacity: 1 TB, Storage media: SSD. On-board graphics card model: Intel Graphics. Operating system installed: Windows 11 Pro, Operating system architecture: 64-bit. Power supply: 360 W. Chassis type: Tower. Product type: PC. Weight: 9.7 kg. Product colour: Black

Specification

Product
Product id	987231
Brand	Dell
Partnr	KHP46
EAN/UPC code	5397184936870
Processor
Processor manufacturer	Intel
Processor family	Intel Core Ultra 9
Processor generation	Intel Core Ultra (Series 2)
Processor model	285
Processor cores	24
Processor boost frequency	5.6 GHz
Performance cores	8
Efficient cores	16
Processor cache	36 MB
Processor cache type	Smart Cache
Performance-core base frequency	2.5 GHz
Processor threads	24
Efficient-core base frequency	1.9 GHz
Efficient-core Max Turbo Frequency	4.6 GHz
Performance-core Max Turbo Frequency	5.4 GHz
Number of processors installed	1
Processor base power	65 W
Maximum turbo power	182 W
Memory
Internal memory	32 GB
Internal memory type	DDR5-SDRAM
Maximum internal memory	128 GB
Memory layout (slots x size)	2 x 16 GB
Memory slots	4x DIMM
Memory channels	Dual-channel
Non-ECC	Y
Memory data transfer rate	5600 MT/s
Neural processor unit (NPU)
Neural processor unit (NPU)	Intel AI Boost
Sparsity support	Y
Windows Studio effects support	Y
AI software frameworks supported by NPU	DirectML, OpenVINO, Windows ML, ONNX RT, WebNN
Total processor performance (up to)	36 TOPs
NPU performance up to	13 TOPs
GPU performance up to	8 TOPs
Storage
Total storage capacity	1000 GB
Optical drive type	N
Storage media	SSD
Number of storage drives installed	1
Total SSDs capacity	1000 GB
Number of SSDs installed	1
SSD memory type	TLC
SSD capacity	1000 GB
SSD interface	PCI Express
NVMe	Y
SSD form factor	M.2
M.2 SSD size	2280 (22 x 80 mm)
Graphics
Discrete graphics adapter	N
On-board graphics adapter	Y
Discrete graphics adapter model	Not available
On-board graphics adapter family	Intel Graphics
On-board GPU manufacturer	Intel
On-board graphics adapter model	Intel Graphics
Network
Ethernet LAN	Y
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Cabling technology	10/100/1000Base-T(X)
LAN controller	Intel I219-LM
Wi-Fi	N
Ports & interfaces
USB 2.0 ports quantity	2
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	2
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity	2
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity	1
USB 3.2 Gen 2x2 Type-C ports quantity	2
Intel® Thunderbolt 4	Y
Thunderbolt 4 ports quantity	1
DisplayPorts quantity	2
DisplayPort version	1.4a
Ethernet LAN (RJ-45) ports	1
Combo headphone/mic port	Y
DC-in jack	Y
Number of SATA III connectors	4
Number of front USB ports	4
Number of rear USB ports	6
Expansion slots
PCI Express x4 (Gen 3. x) slots	2
PCI Express x4 (Gen 4. x) slots	1
PCI Express x16 (Gen 5. x) slots	1
Design
Chassis type	Tower
Volume	32 l
Placement supported	Vertical
Cable lock slot	Y
Cable lock slot type	Kensington
Product colour	Black
Performance
Product type	PC
Market positioning	Business
Motherboard chipset	Intel W880
Audio chip	Realtek ALC3204
Audio system	High Definition Audio
Trusted Platform Module (TPM)	Y
Trusted Platform Module (TPM) version	2.0
Software
Operating system installed	Windows 11 Pro
Operating system architecture	64-bit
Trial software	Activate Your Microsoft 365 For A 30 Day Trial
Power
Power supply	360 W
Power supply input voltage	90 - 264
Power supply input frequency	47/63 Hz
80 PLUS certification	80 PLUS Platinum
Operational conditions
Operating temperature (T-T)	0 - 35 °C
Storage temperature (T-T)	-40 - 65 °C
Operating relative humidity (H-H)	10 - 90 procent
Storage relative humidity (H-H)	0 - 95 procent
Operating altitude	-15.2 - 3048 m
Non-operating altitude	-15.2 - 10668 m
Operating vibration	0.66 G
Non-operating vibration	1.3 G
Operating shock	110 G
Non-operating shock	160 G
Sustainability
Doesn't contain	PVC/BFR
Weight & dimensions
Width	187.7 mm
Depth	438 mm
Height	387 mm
Weight	9700 g
Packaging content
Display included	N
Cables included	AC
Technical details
Sustainability certificates	ENERGY STAR, EPEAT Climate +
