Powerful Switching for your Business
The DGS-1100 Series is a range of powerful switches that offer a lot of bang for your buck. They are great for busy SMBs who expect a lot of their network, including support for surveillance and VoIP. They are packed with traffic management & optimization features that keep your network congestion free. Meanwhile, management tools are flexible and intuitive, making your life easier.

Gigabit Ethernet Speeds
Take your Ethernet speeds to the next level with Gigabit Connectivity

Cutting Edge Green Technology
Innovative D-Link Green power saving features keep your budget in check

Manage Anywhere, Anytime
Remote setup & management is easy, and can be done from anywhere.

Easy to Use & Easy to Install
D-Link Network Assistant Utility (DNA) can quickly discover and do initial setup for D-Link Networking devices such as the DGS-1100 Series, which greatly improves efficiency for solution deployment.

VLANs: Stronger Security & Better Traffic Management
Relatively easy to set up, VLANs can be a big boon for your network. They can isolate sensitive areas of your network, keeping them safe from those with malicious intent, or keeping bandwidth open for latency-sensitive traffic such as VoIP.

For Voice
If VoIP calls make up a large slice of your network usage, separating them onto their own VLAN can ensure they get the bandwidth they need for smooth conversations without lag or jitters.

For Surveillance
If you have surveillance cameras and devices attached to your network, putting them onto their own VLAN keeps surveillance footage running seamlessly. At the same time, it can help prevent a variety of malicious attacks by restricting access to different network areas.

Green Technology
D-Link Green technology enables the DGS-1100 Smart Managed Switches to save power without sacrificing performance. Most of the models in the series utilize a fanless design, for silent and energy-efficient operation. All are IEEE 802.3az-compliant and feature Link Status detection and Time-Based PoE.

Specification

Product
Product id	876369
Brand	D-Link
Partnr	DGS-1100-24PV2/E
EAN/UPC code	790069467837
Data transmission
MAC address table	8000 entries
Switching capacity	48 Gbit/s
Forwarding rate	35.71 Mpps
Store-and-forward	Y
Number of queues	4
Jumbo frames support	Y
Jumbo frames	9216
Packet buffer memory	4.1 MB
Network
Networking standards	IEEE 802.1AX, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1w, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
10G support	N
Copper ethernet cabling technology	10BASE-T, 10BASE-TX, 1000BASE-T
Port mirroring	Y
Full duplex	Y
Flow control support	Y
Auto-negotiation	Y
Auto MDI/MDI-X	Y
Spanning tree protocol	Y
Head-of-line (HOL) blocking	Y
Rate limiting	Y
Broadcast storm control	Y
Link aggregation	Y
VLAN support	Y
Virtual LAN features	Port-based VLAN, Voice VLAN
Number of VLANs	128
Management features
Switch type	Managed
Switch layer	L2
Quality of Service (QoS) support	Y
Web-based management	Y
System event log	Y
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity	24
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Security
DHCP features	DHCP client
IGMP snooping	Y
Queue scheduling algorithms	SPQ, Weighted Round Robin (WRR)
Security algorithms	SNMP, SSL/TLS
Weight & dimensions
Width	280 mm
Depth	230 mm
Height	44 mm
Weight	2200 g
Power
AC input voltage	100 - 240 V
Power consumption (max)	19.5 W
Multicast features
Multicast support	Y
Endurance
Mean time between failures (MTBF)	255003 uur
Design
Rack mounting	Y
Product colour	Black
LED indicators	Y
Certification	EMI FCC A, CE A, VCCI A, C-Tick, BSMI, CCC cUL, CE LVD, CB, BSMI, CCC
Operational conditions
Operating altitude	0 - 2000 m
Heat dissipation	107.5 BTU/h
Storage temperature (T-T)	-40 - 70 °C
Storage relative humidity (H-H)	0 - 95 procent
Operating temperature (T-T)	-5 - 50 °C
Operating relative humidity (H-H)	0 - 95 procent
Performance
Built-in processor	Y
Processor frequency	125 MHz
Memory type	DRAM
Flash memory	16 MB
Fanless	Y
Power over Ethernet (PoE)
Power over Ethernet (PoE)	Y
Power over Ethernet plus (PoE+) ports quantity	12
Power over Ethernet (PoE) power per port	30 W
Total Power over Ethernet (PoE) budget	100 W
