Smart Web UI
The DGS-1100's web user interface is an easy way to manage Layer 2 features, such as VLANs, Spanning Tree Protocol (STP), link aggregation (static). With powerful security features like IGMP snooping, Static MAC, and Storm Control, the DGS-1100 Smart family is a versatile solution for environments that require easy to deploy and easy to configure solutions without added complexities.

Easy to Deploy and Manage
D-Link’s free Network Assistant (DNA) displays all connected devices and speeds up the first time configuration. The free D-View 7 Network Management System comes with a license for 25 nodes and 2 probes and full access to the management tools. Optional upgrade licenses allow you to broaden your network and analysis.

PoE and Poe+, with budgets up to 370W
The DGS-1100 Smart Series includes a range of high power budget PoE-enabled switches for businesses looking to power larger deployments of VoIP phones, wireless access points or network cameras.

Easy Troubleshooting
The DGS-1100 Series features Loopback Detection and Cable Diagnostics to help network administrators find and solve network problems quickly and easily.

Loopback Detection is used to detect loops created by a specific port and automatically shut down the affected port. The Cable Diagnostics feature is designed for network administrators to quickly examine the quality of the copper cables, recognise the cable type, and detect cable errors.

Green Technology
D-Link Green technology enables the DGS-1100 Smart series to save power without sacrifices. The majority of the family utilises a fanless design, for silent and energy efficient operation. All are IEEE 802.3az compliant and feature Link Status detection and Time-Based PoE (excluding DGS-1100-05PD and DGS-1100-08P models).

Surveillance Mode
Select Surveillance Mode in the Web UI to take advantage of easy‑to‑use surveillance features which also enable you to manage your surveillance network effortlessly. It automatically detects your security devices and segments them into a dedicated Auto Surveillance VLAN to handle video surveillance traffic securely and efficiently.

Specification

Product
Product id	876371
Brand	D-Link
Partnr	DGS-1100-26MPV2/E
EAN/UPC code	790069467868
Data transmission
MAC address table	8000 entries
Switching capacity	52 Gbit/s
Forwarding rate	38.69 Mpps
Jumbo frames support	Y
Network
Networking standards	IEEE 802.1D, IEEE 802.1w, IEEE 802.3af, IEEE 802.3at
Copper ethernet cabling technology	10GBASE-T, 1000BASE-T
Port mirroring	Y
Half duplex	Y
Full duplex	Y
Flow control support	Y
Auto-negotiation	Y
Auto MDI/MDI-X	Y
Spanning tree protocol	Y
Head-of-line (HOL) blocking	Y
Rate limiting	Y
Broadcast storm control	Y
Link aggregation	Y
VLAN support	Y
Virtual LAN features	Port-based VLAN, Voice VLAN
Management features
Switch type	Managed
Switch layer	L2
Quality of Service (QoS) support	Y
Web-based management	Y
ARP inspection	Y
MIB support	• RFC768 UDP • RFC791 IP • RFC792 ICMP • RFC793 TCP • RFC826 ARP • RFC1213 MIB II • RFC1493 Bridage MIB • RFC1907 SNMPv2 MIB • RFC1215 MIB Traps Convention
Protocols
IPv4 & IPv6 features	IPv4 FIB
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity	24
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Combo SFP ports quantity	2
Security
DHCP features	DHCP client
IGMP snooping	Y
Security algorithms	SSL/TLS
MAC address filtering	Y
Static port security	Y
Weight & dimensions
Width	440 mm
Depth	208 mm
Height	44 mm
Weight	2800 g
Power
Power supply included	Y
AC input voltage	100 - 240 V
Power consumption (max)	454.1 W
Multicast features
Multicast support	Y
IPv4 multicast entries	1
IPv6 multicast entries	1
Number of multicast groups filtered	1
Design
Rack mounting	Y
Product colour	Black
Housing material	Metal
Operational conditions
Heat dissipation	287 BTU/h
Storage temperature (T-T)	-40 - 70 °C
Storage relative humidity (H-H)	0 - 95 procent
Operating temperature (T-T)	-10 - 50 °C
Operating relative humidity (H-H)	0 - 95 procent
Performance
Flash memory	16 MB
Noise level	50.5 dB
Fanless	Y
MTBF (PoE)	317.777 uur
Harmonized System (HS) code	85176990
Power over Ethernet (PoE)
Power over Ethernet (PoE)	Y
Power over Ethernet (PoE) ports quantity	24
Power over Ethernet plus (PoE+) ports quantity	24
Total Power over Ethernet (PoE) budget	370 W
