Power & Value
The D-Link DGS-1250 Series Smart Managed Switches deliver real value as an Enterprise Access and Small-to-Medium Business (SMB) Access/Aggregation solution. They provide a range of physical interfaces (including a Console Port w/full CLI), multiple management interfaces, 11 Web languages, QoS enablement, and Advanced Layer-2 w/Lite Layer-3 features.

The DGS-1250 Series switches support 24 or 48 x 10/100/1000BASE-T ports, with each switch also supporting an additional 4 x 10G SFP+ ports for optical connections using multimode or single-mode SFP transceivers – enabling real network horsepower at a value price.

Easy Maintenance, Less Downtime
The DGS-1250 Series supports Dual Image and Dual Configuration functionality, as well as a Console Port, all of which make it easier to configure, troubleshoot, and make other changes without interfering with network operation, while full Command Line Interface (CLI) functionality enables remote configuration, without the need for the Internet. And if a network issue ever does occur, the supported Spanning Tree Protocols (STP/RSTP/MSTP) help keep things running without interruptions or downtime.

Automatic Configuration
The DGS-1250 Series supports Auto Voice VLAN and Surveillance Mode, which allow Voice and Video traffic to be automatically identified and handled differently from regular network traffic. Auto Voice VLAN detects Voice over IP (VoIP) traffic and automatically segments it from the rest of the network, increasing security and allowing Quality of Service (QoS) to be applied.

Management Versatility
The DGS-1250 Series comes with the D-Link Network Assistant (DNA) utility so admins can remotely control their network to the port level. DNA allows customers to easily discover multiple D-Link Smart Managed Switches within the same L2 network segment and display them onscreen for instant access.

Specification

Product
Product id	876387
Brand	D-Link
Partnr	DGS-1250-52X/E
EAN/UPC code	790069467899
Data transmission
MAC address table	32000 entries
Switching capacity	176 Gbit/s
Forwarding rate	130.95 Mpps
Static route	Y
Number of static routes	124
Jumbo frames support	Y
Jumbo frames	12000
Packet buffer memory	16 MB
Network
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
10G support	Y
Flow control support	Y
Auto MDI/MDI-X	Y
Spanning tree protocol	Y
Head-of-line (HOL) blocking	Y
Broadcast storm control	Y
Link aggregation	Y
VLAN support	Y
Virtual LAN features	Voice VLAN
Number of VLANs	4094
Management features
Switch type	Managed
Switch layer	L3
Quality of Service (QoS) support	Y
Web-based management	Y
Configuring Location Settings (CLI)	Y
ARP inspection	Y
System event log	Y
MIB support	RFC2893, RFC4213, RFC4291, RFC2464, RFC2462, RFC4862, RFC2461, RFC4861, RFC2573, RFC1321, RFC2284, RFC2865, RFC2716, RFC3580, RFC826, RFC2463, RFC4443, RFC792, RFC793, RFC768, RFC791, RFC2389, RFC4113, RFC4022, RFC2618, RFC2674, RFC1398, RFC1643, RFC1650, RFC2358, RFC2665, RFC2021, RFC271, RFC1757, RFC2819, RFC1442, RFC1901, RFC1902, RFC1903, RFC1904, RFC1905, RFC1906, RFC1907, RFC1908, RFC2578, RFC3418, RFC2573, RFC2575, RFC2576, RFC1212, RFC1213, RFC1215, RFC1493, RFC1157, RFC2620,
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity	48
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
SFP+ module slots quantity	4
Console port	RJ-45
Security
DHCP features	DHCP client, DHCP server, DHCP snooping
Access Control List (ACL)	Y
Access Control List (ACL) rules	768
IGMP snooping	Y
Queue scheduling algorithms	Weighted Round Robin (WRR)
Security algorithms	EAP, LEAP, MD5, PEAP, SSH, SSL/TLS, TTLS
Loop protection	Y
IP-MAC-Port binding	Y
Weight & dimensions
Width	440 mm
Depth	210 mm
Height	44 mm
Weight	3010 g
Packaging data
Package weight	4280 g
Package width	351 mm
Package depth	565 mm
Package height	91 mm
Power
Power supply included	Y
AC input voltage	100 - 240 V
Power consumption (max)	51.2 W
Optical fiber
Fiber ethernet cabling technology	100BASE-FX, 1000BASE-LHX, 1000BASE-X, 1000BASE‑LX, 1000BASE‑SX, 1000BASE‑ZX
Multicast features
Multicast support	Y
Endurance
Mean time between failures (MTBF)	589984.72 uur
Design
Rack mounting	Y
Product colour	Black
LED indicators	Activity, Link, Power, Speed
Electromagnetic compatibility	CE A, VCCI A, FCC A, IC, BSMI
Certification	CB, UL, BSMI, CCC
Operational conditions
Heat dissipation	174.592 BTU/h
Storage temperature (T-T)	-20 - 70 °C
Storage relative humidity (H-H)	0 - 95 procent
Operating temperature (T-T)	-5 - 50 °C
Operating relative humidity (H-H)	0 - 95 procent
Performance
Memory type	DDR3-SDRAM
Internal memory	2048 MB
Flash memory	64 MB
Noise level	50.7 dB
Power over Ethernet (PoE)
Power over Ethernet (PoE)	N
