Power & Value
The D-Link DGS-1250 Series Smart Managed Switches deliver real value as an Enterprise Access and Small-to-Medium Business (SMB) Access/Aggregation solution. They provide a range of physical interfaces (including a Console Port w/full CLI), multiple management interfaces, 11 Web languages, QoS enablement, and Advanced Layer-2 w/Lite Layer-3 features.

The DGS-1250 Series switches support 24 or 48 x 10/100/1000BASE-T ports, with each switch also supporting an additional 4 x 10G SFP+ ports for optical connections using multimode or single-mode SFP transceivers – enabling real network horsepower at a value price.

Easy Maintenance, Less Downtime
The DGS-1250 Series supports Dual Image and Dual Configuration functionality, as well as a Console Port, all of which make it easier to configure, troubleshoot, and make other changes without interfering with network operation, while full Command Line Interface (CLI) functionality enables remote configuration, without the need for the Internet. And if a network issue ever does occur, the supported Spanning Tree Protocols (STP/RSTP/MSTP) help keep things running without interruptions or downtime.

Automatic Configuration
The DGS-1250 Series supports Auto Voice VLAN and Surveillance Mode, which allow Voice and Video traffic to be automatically identified and handled differently from regular network traffic. Auto Voice VLAN detects Voice over IP (VoIP) traffic and automatically segments it from the rest of the network, increasing security and allowing Quality of Service (QoS) to be applied.

High PoE Budget (370W)
The DGS-1250 series offers Power-over-Ethernet (PoE), which simplifies deployment of IP cameras, VoIP phones, Wireless Access Points, and other powered devices. Using the switch’s management interface, an administrator can control various PoE functions, such as remotely rebooting Cameras or Access Points, from anywhere on the network, including over the Internet. All PoE models support the IEEE 802.3af and 802.3at standards.

Extensive Management and Advanced Features
The DGS-1250 Series comes with IGMP snooping, Port Mirroring, Spanning Tree Protocol (STP), and Link Aggregation Control Protocol (LACP). The IEEE 802.3x Flow Control function allows servers to directly connect to the switch for fast, reliable data transfers. The series also supports advanced features such as Static Routing, which allows for communication between different user groups in different VLAN segments in a network.

Specification

Product
Product id	876388
Brand	D-Link
Partnr	DGS-1250-52XMP/E
EAN/UPC code	790069467905
Data transmission
MAC address table	32000 entries
Switching capacity	176 Gbit/s
Forwarding rate	130.95 Mpps
Static route	Y
Number of static routes	124
Jumbo frames support	Y
Jumbo frames	12000
Packet buffer memory	16 MB
Network
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
10G support	Y
Flow control support	Y
Auto MDI/MDI-X	Y
Spanning tree protocol	Y
Head-of-line (HOL) blocking	Y
Broadcast storm control	Y
Link aggregation	Y
VLAN support	Y
Virtual LAN features	Voice VLAN
Number of VLANs	4094
Management features
Switch type	Managed
Switch layer	L3
Quality of Service (QoS) support	Y
Cloud-managed	N
Web-based management	Y
Configuring Location Settings (CLI)	Y
System event log	Y
MIB support	RFC2893, RFC4213, RFC4291, RFC2464, RFC2462, RFC4862, RFC2461, RFC4861, RFC2573, RFC1321, RFC2284, RFC2865, RFC2716, RFC3580, RFC826, RFC2463, RFC4443, RFC792, RFC793, RFC768, RFC791, RFC2389, RFC4113, RFC4022, RFC2618, RFC2674, RFC1398, RFC1643, RFC1650, RFC2358, RFC2665, RFC2021, RFC271, RFC1757, RFC2819, RFC1442, RFC1901, RFC1902, RFC1903, RFC1904, RFC1905, RFC1906, RFC1907, RFC1908, RFC2578, RFC3418, RFC2573, RFC2575, RFC2576, RFC1212, RFC1213, RFC1215, RFC1493, RFC1157, RFC2620,
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity	48
Basic switching RJ-45 Ethernet ports type	N
SFP+ module slots quantity	4
Console port	RJ-45
Security
DHCP features	DHCP client, DHCP server, DHCP snooping
Access Control List (ACL)	Y
Access Control List (ACL) rules	768
IGMP snooping	Y
Queue scheduling algorithms	Weighted Round Robin (WRR)
Security algorithms	EAP, LEAP, PEAP, SSH, TTLS
Loop protection	Y
IP-MAC-Port binding	Y
Weight & dimensions
Width	440 mm
Depth	430 mm
Height	44 mm
Weight	3850 g
Packaging data
Package weight	5170 g
Package width	393 mm
Package depth	563 mm
Package height	89 mm
Power
Power supply included	Y
AC input voltage	100 - 240 V
Power consumption (max)	467.3 W
Multicast features
Multicast support	Y
Endurance
Mean time between failures (MTBF)	309053.1 uur
Design
Rack mounting	Y
Product colour	Black
LED indicators	Activity, Link, Power, Speed
Electromagnetic compatibility	CE A, VCCI A, FCC A, IC, BSMI
Certification	CB, UL, BSMI, CCC
Operational conditions
Heat dissipation	1512.676 BTU/h
Storage temperature (T-T)	-20 - 70 °C
Storage relative humidity (H-H)	0 - 95 procent
Operating temperature (T-T)	-5 - 50 °C
Operating relative humidity (H-H)	0 - 95 procent
Performance
Memory type	DDR3-SDRAM
Internal memory	2048 MB
Flash memory	64 MB
Noise level	51.2 dB
Harmonized System (HS) code	85176990
Technical details
Shipping (inner) case height	428 mm
Pallet height (sea)	1847 mm
Quantity per pallet (sea)	80 stuk(s)
Number of cartons per pallet (sea)	16
Pallet gross weight (sea)	456100 g
Pallet height (air)	1847 mm
Pallet width	1200 mm
Pallet length	1100 mm
Quantity per pallet (air)	80 stuk(s)
Number of cartons per pallet (air)	16
Pallet gross weight (air)	456100 g
Quantity per shipping (inner) case	5 stuk(s)
Shipping (inner) case net weight	22855 g
Shipping (inner) case length	585 mm
Shipping (inner) case width	478 mm
Shipping (inner) case weight	27350 g
Power over Ethernet (PoE)
Power over Ethernet (PoE)	Y
Power over Ethernet (PoE) ports quantity	48
Power over Ethernet (PoE) power per port	15.4 W
Total Power over Ethernet (PoE) budget	370 W
