D-Link 16-Port 2.5G Multi-Gigabit Unmanaged Switch. Switch type: Unmanaged, Switch layer: L2+. Basic switching RJ-45 Ethernet ports type: 2.5G Ethernet (100/1000/2500), Basic switching RJ-45 Ethernet ports quantity: 16. MAC address table: 16000 entries, Switching capacity: 80 Gbit/s. Networking standards: IEEE 802.3, IEEE 802.3ab, IEEE 802.3az, IEEE 802.3bz, IEEE 802.3p, IEEE 802.3u, IEEE 802.3x. DC input voltage: 12 V. Power connector: DC-in jack

Specification

Product
Product id	1003050
Brand	D-Link
Partnr	DMS-1016/E
EAN/UPC code	790069477027
Data transmission
MAC address table	16000 entries
Switching capacity	80 Gbit/s
Forwarding rate	59.52 Mpps
Store-and-forward	Y
Jumbo frames support	Y
Jumbo frames	12288
Network
Networking standards	IEEE 802.3, IEEE 802.3ab, IEEE 802.3az, IEEE 802.3bz, IEEE 802.3p, IEEE 802.3u, IEEE 802.3x
10G support	N
Auto MDI/MDI-X	Y
Ethernet LAN data rates	10, 100, 1000, 2500 Mbit/s
Management features
Switch type	Unmanaged
Switch layer	L2+
Quality of Service (QoS) support	Y
Traffic classification	Y
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity	16
Basic switching RJ-45 Ethernet ports type	2.5G Ethernet (100/1000/2500)
Power connector	DC-in jack
Weight & dimensions
Width	440 mm
Depth	250 mm
Height	44 mm
Weight	2932 g
Packaging data
Quick start guide	Y
Power
Power source	DC
Power supply included	Y
DC input voltage	12 V
Input current	5.4 A
Power consumption (max)	19.135 W
Endurance
Mean time between failures (MTBF)	800034.25 uur
Design
Stackable	Y
Product colour	Black
LED indicators	Y
Certification	LVD; CE Class A, FCC Class A
Operational conditions
Heat dissipation	62.29 BTU/h
Storage temperature (T-T)	-20 - 70 °C
Storage relative humidity (H-H)	0 - 95 procent
Operating temperature (T-T)	-5 - 50 °C
Operating relative humidity (H-H)	10 - 90 procent
Power over Ethernet (PoE)
Power over Ethernet (PoE)	N
