D-Link DMS-3130-30PS. Switch type: Managed, Switch layer: L3. Basic switching RJ-45 Ethernet ports type: 10G Ethernet (100/1000/10000), Basic switching RJ-45 Ethernet ports quantity: 2, USB 2.0 ports quantity: 1, Console port: RJ-45. MAC address table: 32768 entries, Switching capacity: 400 Gbit/s. Networking standards: IEEE 802.11ad, IEEE 802.1ag, IEEE 802.3ah, IEEE 802.1p, IEEE 802.11d, IEEE 802.1s, IEEE 802.1AX,. . . . Power connector: AC-in jack. Power over Ethernet (PoE)

Specification

Product
Product id	894801
Brand	D-Link
Partnr	DMS-3130-30PS/E
EAN/UPC code	790069467172
Data transmission
MAC address table	32768 entries
Switching capacity	400 Gbit/s
Forwarding rate	298 Mpps
Number of queues	8
Jumbo frames support	Y
Jumbo frames	9000
Packet buffer memory	4 MB
Network
Networking standards	IEEE 802.11ad, IEEE 802.1ag, IEEE 802.3ah, IEEE 802.1p, IEEE 802.11d, IEEE 802.1s, IEEE 802.1AX, IEEE 802.3x, IEEE 802.1v, IEEE 802.1Q, IEEE 802.1w, IEEE 802.1x
10G support	Y
Port mirroring	Y
Ethernet Ring Protection Switching (ERPS)	Y
Flow control support	Y
Fast leave	Y
Spanning tree protocol	Y
Broadcast storm control	Y
Link aggregation	Y
VLAN support	Y
Virtual LAN features	Protocol-based VLAN, MAC address-based VLAN, Port-based VLAN, Voice VLAN, Multicast VLAN, Private VLAN
Number of VLANs	4000
Management features
Switch type	Managed
Switch layer	L3
Quality of Service (QoS) support	Y
Web-based management	Y
System event log	Y
Protocols
GARP VLAN Registration Protocol (GVRP)	Y
Routing protocols	OSPFv2, RIPng, OSPFv3, RIP-1, RIP-2
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity	2
Basic switching RJ-45 Ethernet ports type	10G Ethernet (100/1000/10000)
10G Ethernet (copper) ports quantity	2
SFP module slots quantity	24
Console port	RJ-45
USB 2.0 ports quantity	1
Power connector	AC-in jack
Security
DHCP features	DHCP client, DHCP relay, DHCP server, DHCP snooping
Access Control List (ACL)	Y
Access Control List (ACL) egress	512
Access Control List (ACL) ingress	2048
IGMP entries	1024
IGMP snooping	Y
Queue scheduling algorithms	Weighted Round Robin (WRR), Weighted random early detection (WRED), Strict Priority Queue (SPQ)
Packet filtering	L3
Authentication type	RADIUS, TACACS+
DoS attack prevention	Y
Static port security	Y
SSH/SSL support	Y
Loop protection	Y
BPDU filtering/protection	Y
Authentication	Guest VLAN
Root protection	Y
Weight & dimensions
Width	440 mm
Depth	250 mm
Height	250 mm
Weight	6540 g
Power
Power source	AC
Power supply included	Y
Redundant power supply (RPS) support	Y
AC input voltage	100 - 240 V
Power consumption (max)	1211.5 W
Surge protection	Y
Surge protection voltage	6 kV
Multicast features
Multicast support	Y
MLD entries	64
Endurance
Mean time between failures (MTBF)	487153 uur
Design
Stackable	Y
Product colour	Black
Number of fans	3 ventilator(en)
Safety	CB, cUL, BSMI, CCC
Certification	FCC Class A, CE Class A, VCCI Class A, IC, RCM, BSMI, CCC
Operational conditions
Heat dissipation	413.73 BTU/h
Storage temperature (T-T)	-40 - 70 °C
Storage relative humidity (H-H)	5 - 90 procent
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	10 - 90 procent
Performance
Physical stacking (units)	9
Virtual stacking (units)	32
sFlow	Y
Noise level	54 dB
Power over Ethernet (PoE)
Power over Ethernet (PoE)	Y
Power over Ethernet (PoE) ports quantity	16
Power over Ethernet (PoE) power per port	60 W
Total Power over Ethernet (PoE) budget	960 W
