8 ports Gigabit PoE+2 ports Gigabit SF



D-Link
Not in stock
€ 188,95
€ 228,62 incl 21% VAT
Enjoy the Power of Next-Gen Surveillance Switch
Enhance your surveillance environment with the DSS-200G, a smart and easily installed device that delivers greater control and flexibility. Discover the capabilities of this intelligent tool that automates processes and adds intelligence to your network.

Built for Surveillance,
with Gigabit Ethernet & PoE++

Designed to meet surveillance requirements for businesses of all sizes, with features like support for high-powered PTZ cameras, high PoE budgets, Auto Surveillance VLAN, and surge protection, these switches are ideal for IP surveillance setups.

Long Range PoE Delivery
Connect and power cameras up to 250 metres away without the need for additional PoE extenders.

Power Your Devices
Supports PoE/PoE+ to connect and power your PoE-cable network devices via Ethernet cables without the need for power adapters.

Reliable PoE Connections
Surge protection on all PoE ports protects the switch when feeding power to PoE-capable devices.

Rapid deployments with a single PoE cable.
The series supports PoE, and some provide higher power PoE++, delivering up to 90 watts on selected ports, enabling faster deployment of PoE devices such as IP cameras, VoIP phones, access points, terminals, speakers, lights, conferencing systems, displays, and more.

Reach further with a flick of a switch.
The built-in DIP switch allows easy configuration and quick adjustment of application settings without the need to access the web configuration. Quickly enable and disable functions such as QoS, Extend (connection by up to 250 metres), Port Isolation, PD-Alive and STP (Spanning Tree Protocol) in an instant.

Protects the network against power surges.
6kV surge protection on all PoE ports protects the network against voltage spikes with link aggregation, ERPS and STP support to make your network more robust and resilient.

Connect to more with PoE++
See your remaining power availability with the built-in PoE Power Budget LEDs for 25%, 50%, 75%, and 100% power usage at a glance. And utilise up to 518W, with 90W on 8 ports and 30W on 15 ports for DSS-200G-28MPP, so you can rapidly deploy more devices.

Layer 2 management features.
Comes with a complete line-up of L2 features, including port mirroring, Spanning Tree Protocol (STP), and Link Aggregation Control Protocol (LACP). Network maintenance features such as loopback detection and cable diagnostics.

Quality of Service and bandwidth control.
Bandwidth control allows network administrators to reserve bandwidth for important functions that require higher priority or more bandwidth.

Auto Surveillance VLAN consolidates data and surveillance video transmission through a single switch, sparing businesses the expense of dedicated hardware and facilities.

Voice VLAN enhances the VoIP service by automatically placing voice traffic from IP phones to a designated VLAN. With a prioritised and segmented VLAN, this feature guarantees quality and security of VoIP traffic.

Energy efficient
With built-in D-Link Green technology, this series saves power without sacrificing operational performance or functionality.

Time-Based PoE
Schedule the ports on the switch to provide PoE power to devices on specific days and during set hours of the week for energy savings

Sleep mode
Link status drastically reduces power consumption by automatically putting ports without a link into a sleep mode

Advanced chipset
The series incorporates a special chipset with advanced silicon technology for efficient use of energy

We're here to help.
Over 35 years in the networking industry

Innovative end-to-end solution experts for small businesses to large corporations around the world.

Talking to us is easy
Skilled local support in 16 countries. Our support teams are ready to help you.

Specification

Product
Product id 894808
Brand D-Link
Partnr DSS-200G-10MP/E
EAN/UPC code 790069468063
Warranty (months) 5 years
Data transmission
MAC address table 8000 entries
Switching capacity 20 Gbit/s
Forwarding rate 14.88 Mpps
Number of queues 4
Jumbo frames support Y
Jumbo frames 10240
Packet buffer memory 4.1 MB
Network
Networking standards IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x
Port mirroring Y
Half duplex Y
Full duplex Y
Flow control support Y
Auto-negotiation Y
Auto MDI/MDI-X Y
Spanning tree protocol Y
Head-of-line (HOL) blocking Y
Rate limiting Y
Broadcast storm control Y
Link aggregation Y
Ethernet LAN data rates 1000 Mbit/s
VLAN support Y
Virtual LAN features Voice VLAN
Number of VLANs 4094
Management features
Switch type Managed
Switch layer L2
Quality of Service (QoS) support Y
Web-based management Y
Traffic classification Y
MIB support • RFC768 UDP • RFC791 IP • RFC792 ICMP • RFC793 TCP • RFC826 ARP • RFC1213 MIB II • RFC1493 Bridage MIB • RFC1907 SNMPv2 MIB • RFC1215 MIB Traps Convention • RFC2233 Interface Group MIB • RFC2665 Ether-like MIB • RFC4363 IEEE 802.1p MIB • ZoneDefense MIB • Private MIB • RFC951 BootP client • RFC1542 BootP/DHCP client • RFC2236 IGMP Snooping
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity 8
Basic switching RJ-45 Ethernet ports type Gigabit Ethernet (10/100/1000)
Installed SFP modules quantity 2
Security
IGMP snooping Y
Queue scheduling algorithms Strict Priority Queue (SPQ), Weighted Round Robin (WRR)
SSH/SSL support Y
Password protection Y
Weight & dimensions
Width 280 mm
Depth 180 mm
Height 44 mm
Weight 1550 g
Power
Power source AC
Power supply included Y
AC input voltage 100 - 240 V
AC input frequency 50/60 Hz
Input current 1.7 A
Power consumption (max) 160.2 W
Multicast features
Multicast support Y
Multicast features Controllable multicast
Endurance
Mean time between failures (MTBF) 345045 uur
Design
Form factor 1U
Product colour Grey
Reset button Y
LED indicators Activity, Alarm, Link, Power, Speed
Operational conditions
Heat dissipation 103.05 BTU/h
Storage temperature (T-T) -40 - 70 °C
Storage relative humidity (H-H) 0 - 95 procent
Operating temperature (T-T) -5 - 50 °C
Operating relative humidity (H-H) 0 - 95 procent
Performance
Memory type DDR3-SDRAM
Internal memory 128 MB
Flash memory 32 MB
Fanless Y
Technical details
Sustainability certificates BSMI, CB, CE, Federal Communications Commission (FCC), Low Voltage Directive (LVD), UL ECOLOGO, cUL
Sustainability compliance Y
Power over Ethernet (PoE)
Power over Ethernet (PoE) Y
Power over Ethernet (PoE) ports quantity 8
Power over Ethernet (PoE) power per port 30 W
Total Power over Ethernet (PoE) budget 130 W
Other features
Input voltage 100 - 240 V
