Versatile Traffic Management
Optimizes critical services with QoS, traffic shaping, multicast support, and ISM VLAN for enhanced efficiency

Simplified Management
The SIM feature enables managing multiple switches as a virtual stack with a single IP, supporting diverse management tools

Boosted Network Reliability
AC or DC RPS options ensure uninterrupted operation and boost switch reliability by preventing power disruptions

Advanced Security for Access
Supports authentication mechanisms such as 802.1X, Web/MAC-based access control for the easy deployment

High Availability and Scalability
Stack up to 9 switches with 200 Gbps bandwidth and unified IP for simplified control, fast failover and solid redundancy

Efficient Layer 3 Routing
Enables Layer 3 routing between different parts of your network, improving efficiency by directing traffic to its optimal destination

High-Speed Versatile Switching
Featuring flexible combinations of 10G SFP+ and 10GBase-T downlink ports + 4×10/25G SFP28 uplinks, this switch delivers flexible, high-performance connectivity. The 100M-10G auto-sensing ports optimize speed while 25G-capable uplinks handle heavy traffic. The full optical interface design optimizes speed and handles heavy traffic.

Perfect as a core switch for SMBs, enterprise aggregation, or Metro Ethernet edge, it combines rich software features with robust security for diverse deployments.

Unified the Power, Stack for Success
Scale your network with the DXS-3130 series by stacking up to 9 switches into a single physical or virtual unit. This simplifies management, improves redundancy, and allows control of the entire stack through one IP address. With up to 200 Gbps, physical stacking boosts capacity to meet growing network demands.

Built for Unbreakable Networks
The DXS-3130-32S ensures continuous uptime with redundant power and stacking. It's 50ms ERPS recovery minimizes downtime, loopback detection blocks storm-affected ports, and VRRP provides seamless backup routing making it ideal for hospitals, factories, and other mission-critical networks.

Optimized Performance for Critical Services
The DXS-3130-32S switch prioritizes mission-critical traffic like VoIP and IPTV through advanced QoS/CoS, traffic shaping, and L2 Multicast (IGMP/MLD Snooping). ISM VLAN further enhances bandwidth efficiency and security for multicast streaming.

Advanced QoS/CoS
Prioritizes critical traffic like VoIP and video, ensuring smooth performance and minimal latency for time-sensitive applications

IGMP/MLD Snooping
Multicast traffic streams only to intended recipients, reducing unnecessary bandwidth usage and enhancing network efficiency

ISM VLAN
Controls multicast across VLANs to reduce traffic and enhance security and performance on the large-scale network

Specification

Product
Product id	1025675
Brand	D-Link
Partnr	DXS-3130-32S/E
EAN/UPC code	790069476952
Data transmission
MAC address table	32768 entries
Switching capacity	760 Gbit/s
Forwarding rate	560.44 Mpps
Network
Networking standards	IEEE 802.1D, IEEE 802.1w, IEEE 802.1s, IEEE 802.1v, IEEE 802.3x, IEEE 802.1p, IEEE 802.3ah
10G support	Y
Copper ethernet cabling technology	10GBASE-T
Full duplex	Y
Flow control support	Y
Broadcast storm control	Y
Ethernet LAN data rates	10000, 25000 Mbit/s
VLAN support	Y
Virtual LAN features	Multicast VLAN, Tagged VLAN, VLAN Identifier ( VLAN ID)
Management features
Switch type	Managed
Switch layer	L2/L3
Quality of Service (QoS) support	Y
Web-based management	Y
Traffic classification	Y
Ports & interfaces
Basic switching RJ-45 Ethernet ports type	N
SFP+ module slots quantity	28
SFP28 ports quantity	4
Security
IGMP snooping	Y
Authentication type	IEEE 802.1x
Loop protection	Y
Weight & dimensions
Width	440 mm
Depth	250 mm
Height	44 mm
Weight	3835 g
Power
Power source	AC
Power supply included	Y
AC input voltage	100 - 240 V
AC input frequency	50/60 Hz
Power consumption (max)	66.5 W
Multicast features
Multicast support	Y
Design
Stackable	Y
Form factor	1U
Product colour	Silver
LED indicators	Power, Status, Link, Fan
Number of fans	3 ventilator(en)
Operational conditions
Storage temperature (T-T)	-40 - 70 °C
Storage relative humidity (H-H)	5 - 90 procent
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	10 - 90 procent
Power over Ethernet (PoE)
Power over Ethernet (PoE)	N
