With its wide color gamut, enormous 1800:1 contrast ratio, state-of-the-art USB-C connectivity and pre-installed HDR presets, the CG2400S is the ideal tool for professional creatives. The CG2400S with Wide Gamut IPS panel, 10-bit color depth and 16-bit 3D Look-Up-Table (LUT) offers perfect precision, smooth color transitions and nuances. The Adobe RGB color space is covered by 99% and the DCI-P3 color space by 98%. Thanks to the presets for HLG and the PQ gamma curves, even the smallest model in the ColorEdge CG series can be ideally integrated into HDR production workflows. The integrated calibration sensor enables effortless, automatic calibration. Thanks to the universal connectivity via USB-C, a single cable is used to transmit the image signal and power the monitor’s USB hub. It can also be used to supply a mobile device with up to 70 watts of charging current. In combination with the integrated USB hub, the CG2400S becomes the central dock for creative workflows in a single operation. Of course, an HDMI and DisplayPort connection are also on board. The supplied light protection screen rounds off the CG2400S’s extensive features.

Specification

Product
Product id	994094
Brand	Eizo
Partnr	CG2400S
EAN/UPC code	4995047067818
Warranty (months)	5 years
Technical details
Compliance certificates	CB, CCC, CE, China RoHS, Federal Communications Commission (FCC), PSE, RCM, RoHS, TÜV mark, UKCA, VCCI, WEEE, cTUVus
Display
Display diagonal	24 inch
Display resolution	1920 x 1200 Pixels
Native aspect ratio	16:10
Panel type	IPS
Display brightness (typical)	400 cd/m²
Response time	11 ms
HD type	WUXGA
Response time measurement type	GTG (Gray to Gray)
Display technology	LCD
LED backlight	Y
Contrast ratio (typical)	1800:1
Maximum refresh rate	60 Hz
Viewing angle, horizontal	178 °
Viewing angle, vertical	178 °
Display number of colours	1.07 billion colours
Display diagonal (metric)	61 cm
Pixel pitch	0.27 x 0.27 mm
Digital horizontal frequency	15 - 76 kHz
Digital vertical frequency	23 - 61 Hz
sRGB coverage (typical)	100 procent
Adobe RGB coverage	99 procent
Colour gamut standard	Adobe RGB, DCI-P3, Rec. 709, sRGB
Performance
NVIDIA G-SYNC	N
AMD FreeSync	N
Flicker-free technology	Y
Multimedia
Built-in speaker(s)	N
Built-in camera	N
Design
Market positioning	Graphics design
Product colour	Black
Feet colour	Black
Certification	CE, UKCA, CB, TÜV/GS, TÜV/Ergonomics (including ISO 9241-307), RCM, cTÜVus, FCC-B, CAN ICES-3 (B), TÜV/S, PSE, VCCI-B, RoHS, WEEE, China RoHS, CCC
Ports & interfaces
Built-in USB hub	Y
USB hub version	3.2 Gen 1 (3.1 Gen 1)
Number of USB Type-B upstream ports quantity	1
Number of USB Type-C upstream ports quantity	1
USB Type-A downstream ports quantity	4
USB Type-C DisplayPort Alternate Mode	Y
USB Power Delivery up to	70 W
HDMI	Y
DisplayPorts quantity	1
Headphone out	N
Built-in KVM switch	Y
Ergonomics
VESA mounting	Y
Panel mounting interface	100 x 100 mm
Cable lock slot	Y
Cable lock slot type	Kensington
Adjustable height (max)	155 mm
Height adjustment	Y
Swivelling	Y
Pivot angle	-90 - 90 °
Pivot	Y
Swivel angle range	0 - 344 °
Tilt angle range	-5 - 35 °
Tilt adjustment	Y
On Screen Display (OSD)	Y
On Screen Display (OSD) languages	DEU, ENG, ESP, FRE, ITA, SWE
Packaging data
Cables included	HDMI, Power, USB Type-A to USB Type-B, USB Type-C to USB Type-C
Quick start guide	Y
Power
Energy efficiency class (SDR)	E
Energy consumption (SDR) per 1000 hours	16 kWu
Power consumption (typical)	17 W
Energy efficiency class (HDR)	Not available
Power consumption (standby)	0.5 W
Power consumption (max)	150 W
AC input voltage	100 - 240 V
AC input frequency	50/60 Hz
Energy efficiency scale	A to G
Weight & dimensions
Width (with stand)	554.4 mm
Depth (with stand)	245 mm
Height (with stand)	408.1 mm
Weight (with stand)	8500 g
Width (without stand)	554.4 mm
Depth (without stand)	70.2 mm
Height (without stand)	374.1 mm
Weight (without stand)	5500 g
Other features
USB Power Delivery	Y
Colour gamut DCI-P3	98 procent
Touchscreen	N
