With its compact 24" size, SDI connectivity, and HDR support, the ColorEdge CG2400SV is the ideal monitor for editing suites, studios, and mobile productions in the film and broadcast industry. The SDI input and output (3G-SDI Level A and HD-SDI) enable loss-free transmission of uncompressed video signals ś perfect for use with camera systems and live feeds. HDMI and DisplayPort are also available. With a maximum brightness of 400 cd/m² and a contrast ratio of 1800:1, the CG2400SV meets the requirements of the DCI standard. Support for HLG and PQ gamma curves ensures accurate HDR display ś ideal for postproduction and on-set monitoring. The Wide Gamut IPS panel covers 98% of the DCI-P3 color space and supports the BT.2020 standard. With 10-bit display and a 16-bit 3D LUT, the monitor delivers accurate color reproduction and smooth transitions - essential for color-critical applications. The integrated calibration sensor enables effortless, automatic calibration. With the Pixel Inspection function, users can directly check whether the signal processing is correctly set throughout the entire workflow. The integrated USB hub, headphone jack, and included light shield round out the CG2400SV’s extensive features.

Specification

Product
Product id	999363
Brand	Eizo
Partnr	CG2400SV
EAN/UPC code
Warranty (months)	5 years
Technical details
Compliance certificates	CB, CCC, CE, China RoHS, Federal Communications Commission (FCC), ICES, PSE, RCM, RoHS, TÜV mark, UKCA, VCCI, WEEE
Display
Display diagonal	24.1 inch
Display resolution	1920 x 1200 Pixels
Native aspect ratio	16:10
Panel type	IPS
Display brightness (typical)	120 cd/m²
Response time	11 ms
HD type	WUXGA
Display technology	LCD
LED backlight	Y
Screen shape	Flat screen
Contrast ratio (typical)	1800:1
Maximum refresh rate	60 Hz
Viewing angle, horizontal	178 °
Viewing angle, vertical	178 °
Display number of colours	1.07 billion colours
Display diagonal (metric)	61.1 cm
Pixel density	94 ppi
Pixel pitch	0.27 x 0.27 mm
Viewable size, horizontal	518.4 mm
Viewable size, vertical	324 mm
Digital horizontal frequency	26 - 76 kHz
Digital vertical frequency	23 - 61 Hz
High Dynamic Range (HDR) technology	Hybrid Log-Gamma (HLG)
Colour depth	10 Bit
sRGB coverage (typical)	100 procent
Adobe RGB coverage	99 procent
Colour gamut standard	Adobe RGB, DCI-P3, Rec. 709, sRGB
Performance
NVIDIA G-SYNC	N
AMD FreeSync	N
Flicker-free technology	Y
Multimedia
Built-in speaker(s)	N
Built-in camera	N
Design
Market positioning	Graphics design
Product colour	Black
Feet colour	Black
Certification	CE, UKCA, CB, TÜV/GS, TÜV/Ergonomics (including ISO 9241-307), RCM, cTÜVus, FCC-B, CAN ICES-3 (B), TÜV/S, PSE, VCCI-B, RoHS, WEEE, China RoHS, CCC
Ports & interfaces
Built-in USB hub	Y
USB hub version	3.2 Gen 1 (3.1 Gen 1)
Number of USB Type-B upstream ports quantity	2
USB Type-A downstream ports quantity	4
USB Power Delivery up to	70 W
HDMI	Y
HDMI ports quantity	1
DisplayPorts quantity	1
Headphone out	Y
Headphone connectivity	3.5 mm
Built-in KVM switch	Y
HDCP	Y
Ergonomics
VESA mounting	Y
Panel mounting interface	100 x 100 mm
Adjustable height (max)	155 mm
Height adjustment	Y
Swivelling	Y
Pivot angle	-90 - 90 °
Pivot	Y
Swivel angle range	0 - 344 °
Tilt angle range	-5 - 35 °
Tilt adjustment	Y
On Screen Display (OSD)	Y
On Screen Display (OSD) languages	DEU, ENG, ESP, FRE, ITA, SWE
Packaging data
Stand included	Y
Cables included	HDMI, Power, USB Type-A to USB Type-B
Quick start guide	Y
Power
Energy efficiency class (SDR)	Not available
Power consumption (typical)	17 W
Energy efficiency class (HDR)	Not available
Power consumption (standby)	0.5 W
Power consumption (max)	150 W
AC input voltage	100 - 240 V
AC input frequency	50 Hz
Weight & dimensions
Width (with stand)	554.4 mm
Depth (with stand)	245 mm
Height (with stand)	408.1 mm
Weight (with stand)	8500 g
Width (without stand)	554.4 mm
Depth (without stand)	70.2 mm
Height (without stand)	374.1 mm
Weight (without stand)	5500 g
Other features
Display brightness (peak)	400 cd/m²
USB Power Delivery	Y
Colour gamut DCI-P3	98 procent
Touchscreen	N
