The ColorEdge CG3100X is the top model in the ColorEdge series. With a generous screen diagonal of 30.5 inches and DCI-4K resolution (4096 × 2160 pixels), it meets all the requirements of professional users in film post-production, color grading, and image editing. Thanks to pre-installed PQ and HLG HDR presets and a maximum brightness of 500 cd/m², the CG3100X can be seamlessly integrated into modern HDR workflows. Photographers, content creators, and digital artists benefit from the generous 17:9 format, which offers plenty of space for creative expression with a razor-sharp detail resolution of 152 ppi. The wide color gamut coverage of common standard color spaces such as Rec709, Rec2020, DCI-P3, and AdobeRGB, as well as the 24-bit 3D LUT, ensure realistic and high-contrast color reproduction with maximum precision. The CG3100X also impresses in terms of connectivity: Notebooks can be connected via USB-C with just one cable - including image and data transfer as well as power supply with up to 94 watts. In addition to a DisplayPort connection, there is also a powerful HDMI connection that even supports uncompressed DCI 4K (4:4:4) material in 12 bits at up to 60 Hz - ideal for HDMI-based production environments. An integrated calibration sensor enables effortless, automatic self-calibration, while the RJ45 LAN port, USB hub, and included light shield round out the CG3100X’s professional features.

Specification

Product
Product id	999362
Brand	Eizo
Partnr	CG3100X
EAN/UPC code
Warranty (months)	5 years
Technical details
Compliance certificates	CB, CE, Federal Communications Commission (FCC), PSE, RCM, RoHS, TÜV mark, UKCA, VCCI, WEEE
Display
Display diagonal	30.5 inch
Display resolution	4096 x 2160 Pixels
Native aspect ratio	17:9
Panel type	IPS
Display brightness (typical)	120 cd/m²
Response time	15 ms
HD type	4K DCI
Response time measurement type	GTG (Gray to Gray)
Display technology	LCD
LED backlight	Y
Screen shape	Flat screen
Supported graphics resolutions	640 x 480 (VGA), 720 x 400, 800 x 600 (SVGA), 1024 x 768 (XGA), 1280 x 1024 (SXGA), 1600 x 1200 (UXGA), 1680 x 1050 (WSXGA+), 1920 x 1200 (WUXGA), 2560 x 1440, 2560 x 1600 (WQXGA), 3840 x 2160, 4096 x 2160
Contrast ratio (typical)	1800:1
Maximum refresh rate	60 Hz
Viewing angle, horizontal	178 °
Viewing angle, vertical	178 °
Display number of colours	1.07 billion colours
Display diagonal (metric)	77.5 cm
Pixel density	152 ppi
Pixel pitch	0.167 x 0.167 mm
Horizontal scan range	15 - 136 kHz
Vertical scan range	23 - 61 Hz
Viewable size, horizontal	685.7 mm
Viewable size, vertical	361.6 mm
Digital horizontal frequency	25 - 137 kHz
Digital vertical frequency	23 - 61 Hz
High Dynamic Range (HDR) technology	Hybrid Log-Gamma (HLG)
Colour depth	10 Bit
sRGB coverage (typical)	100 procent
Adobe RGB coverage	97 procent
Colour gamut standard	Adobe RGB, DCI-P3, Rec. 709, sRGB
Performance
NVIDIA G-SYNC	N
AMD FreeSync	N
Flicker-free technology	Y
Multimedia
Built-in speaker(s)	N
Built-in camera	N
Design
Market positioning	Graphics design
Product colour	Black
Feet colour	Black
Certification	CE, UKCA, CB, TÜV/GS, TÜV/Ergonomics (including ISO 9241-307), FograCert Softproofing System (class A), RCM, cTÜVus, FCC-B, CAN ICES-3 (B), TÜV/S, PSE, VCCI-A, RoHS, WEEE
Ports & interfaces
Built-in USB hub	Y
USB hub version	3.2 Gen 1 (3.1 Gen 1)
Number of USB Type-B upstream ports quantity	1
Number of USB Type-C upstream ports quantity	1
USB Type-A downstream ports quantity	4
USB Type-C DisplayPort Alternate Mode	Y
USB Power Delivery up to	94 W
HDMI	Y
HDMI ports quantity	1
DisplayPorts quantity	1
Headphone out	Y
Headphone connectivity	3.5 mm
HDCP version	2.3
Built-in KVM switch	Y
HDCP	Y
Ergonomics
VESA mounting	Y
Panel mounting interface	100 x 100 mm
Cable lock slot	Y
Cable lock slot type	Kensington
Adjustable height (max)	155 mm
Height adjustment	Y
Swivelling	Y
Swivel angle range	0 - 344 °
Tilt angle range	-5 - 35 °
Tilt adjustment	Y
On Screen Display (OSD)	Y
On Screen Display (OSD) languages	DEU, ENG, ESP, FRE, ITA, SWE
Packaging data
Stand included	Y
Cables included	HDMI, Power, USB Type-A to USB Type-B, USB Type-C to USB Type-C
Quick start guide	Y
Power
Energy efficiency class (SDR)	G
Energy consumption (SDR) per 1000 hours	52 kWu
Power consumption (typical)	86 W
Energy efficiency class (HDR)	Not available
Power consumption (standby)	0.5 W
Power consumption (max)	270 W
AC input voltage	100 - 240 V
AC input frequency	50/60 Hz
Energy efficiency scale	A to G
Weight & dimensions
Width (with stand)	721 mm
Depth (with stand)	290 mm
Height (with stand)	428.1 mm
Weight (with stand)	12300 g
Width (without stand)	721 mm
Depth (without stand)	87.2 mm
Height (without stand)	413.9 mm
Weight (without stand)	8900 g
Other features
Display brightness (peak)	500 cd/m²
USB Power Delivery	Y
Colour gamut DCI-P3	99 procent
Touchscreen	N
Manual	Y
Ethernet LAN	Y
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN (RJ-45) ports	1
