The ColorEdge CS3200X offers visual reliability on a 31.5-inch display and is the ideal tool for all creative professionals. Whether your content is photographed, filmed, scanned, drawn, or AI-generated – one thing is always essential: reliability and precision. And you can never have enough screen space. That’s exactly what the CS3200X offers with its 31.5-inch screen diagonal and razor-sharp 4K UHD display. This ensures that image content, user interfaces, tools, and the timeline are all displayed clearly and at an optimal size. The CS3200X covers 99% of the Adobe RGB and 96% of the DCI-P3 color spaces – ideal conditions for image editing, post-production, color grading, and printing. Numerous pre-calibrated presets, such as Adobe RGB, DCI-P3, and BT.709, allow for quick switching between different production standards. When used with Apple devices, the Display P3 preset ensures consistent image reproduction. Thanks to presets for HLG and PQ gamma, the CS3200X integrates seamlessly into professional HDR workflows. In Sync Signal mode, brightness, gamma, and color space are even automatically adjusted according to the video signal’s metadata. Via USB-C, the monitor transmits video signals, USB data, and up to 70 watts of charging power. HDMI and DisplayPort are also available. The integrated KVM switch allows for convenient use of USB accessories with multiple computers, and the included light shield rounds out the extensive feature set.

Specification

Product
Product id	1029188
Brand	Eizo
Partnr	CS3200X
EAN/UPC code	4995047071280
Warranty (months)	5 Years
Technical details
Warranty period	5 jaar
Compliance certificates	UKCA, CB, RCM, ICES, VCCI, RoHS, WEEE, PSE, CE, TÜV mark
Display
Display diagonal	31.5 inch
Display resolution	3840 x 2160 Pixels
Native aspect ratio	16:9
Panel type	IPS
Display brightness (typical)	350 cd/m²
Response time	14 ms
HD type	4K Ultra HD
Response time measurement type	GTG (Gray to Gray)
Display technology	LCD
LED backlight	Y
Backlight type	W-LED
Hardware calibration	Y
Anti-glare screen	Y
Screen shape	Flat screen
Supported graphics resolutions	3840 x 2160, 2560 x 1600 (WQXGA), 2560 x 1440, 1920 x 1200 (WUXGA), 1920 x 1080 (HD 1080), 1680 x 1050 (WSXGA+), 1600 x 1200 (UXGA), 1280 x 1024 (SXGA), 1024 x 768 (XGA), 800 x 600 (SVGA), 720 x 400, 640 x 480 (VGA)
Supported video modes	1080i, 1080p, 720p, 576p, 480i
Contrast ratio (typical)	1300:1
Maximum refresh rate	60 Hz
Viewing angle, horizontal	178 °
Viewing angle, vertical	178 °
Display number of colours	1.07 billion colours
Display diagonal (metric)	80 cm
Pixel density	140 ppi
Pixel pitch	0.182 x 0.182 mm
Viewable size, horizontal	697.3 mm
Viewable size, vertical	392.2 mm
Digital horizontal frequency	25 - 137 kHz
Digital vertical frequency	23 - 61 Hz
High Dynamic Range (HDR) technology	Hybrid Log-Gamma (HLG)
High Dynamic Range (HDR) supported	Y
Colour depth	10 Bit
sRGB coverage (typical)	100 procent
Adobe RGB coverage	99 procent
Colour gamut standard	Adobe RGB, DCI-P3, sRGB, Rec. 709, EBU, SMPTE-C
Performance
NVIDIA G-SYNC	N
AMD FreeSync	N
Flicker-free technology	Y
Multimedia
Built-in speaker(s)	N
Built-in camera	N
Design
Market positioning	Photo editing
Product colour	Black
Feet colour	Black
Certification	CE, UKCA, CB, RCM, cTÜVus, FCC-B, CAN ICES-3 (B), PSE, VCCI-B, RoHS, WEEE
Ports & interfaces
Built-in USB hub	Y
USB hub version	2.0 / 3.2 Gen 1 (3.1 Gen 1)
USB upstream port type	USB Type-B, USB Type-C
Number of upstream ports	2
Number of USB Type-B upstream ports quantity	1
Number of USB Type-C upstream ports quantity	1
USB Type-A downstream ports quantity	4
USB Type-C DisplayPort Alternate Mode	Y
USB Power Delivery up to	70 W
HDMI	Y
HDMI ports quantity	1
DisplayPorts quantity	1
Built-in KVM switch	Y
HDCP	Y
Ergonomics
VESA mounting	Y
Panel mounting interface	100 x 100 mm
Adjustable height (max)	141.8 mm
Height adjustment	Y
Swivelling	Y
Swivel angle range	0 - 344 °
Tilt angle range	-5 - 35 °
Tilt adjustment	Y
On Screen Display (OSD)	Y
On Screen Display (OSD) languages	DEU, ENG, FRE, ESP, ITA, SWE
Packaging data
Stand included	Y
Cables included	HDMI, USB Type-C to USB Type-C, USB Type-A to USB Type-B, Power
Quick start guide	Y
Packaging content
Sun hood included	Y
Power
Energy efficiency class (SDR)	E
Energy consumption (SDR) per 1000 hours	27 kWu
Power consumption (typical)	25 W
Energy efficiency class (HDR)	Not available
Power consumption (standby)	0.5 W
Power consumption (max)	166 W
AC input voltage	100 - 240 V
AC input frequency	50/60 Hz
Energy efficiency scale	A to G
Operational conditions
Operating temperature (T-T)	0 - 35 °C
Storage temperature (T-T)	-20 - 60 °C
Operating relative humidity (H-H)	20 - 80 procent
Storage relative humidity (H-H)	10 - 90 procent
Weight & dimensions
Width (with stand)	712.7 mm
Depth (with stand)	245 mm
Height (with stand)	431.5 mm
Weight (with stand)	10600 g
Width (without stand)	712.7 mm
Depth (without stand)	69.3 mm
Height (without stand)	420.5 mm
Weight (without stand)	7700 g
Logistics data
Harmonized System (HS) code	85285210
Other features
USB Power Delivery	Y
Colour gamut DCI-P3	96 procent
Power supply type	Internal
Touchscreen	N
Look-up table (LUT) bit depth	16
