Product |
Product id
| 949344
|
Brand
| Eizo
|
Partnr
| MX317W
|
EAN/UPC code
|
|
Display |
Display diagonal
| 30.5 inch
|
Display resolution
| 4096 x 2160 Pixels
|
Native aspect ratio
| 17:9
|
Panel type
| IPS
|
Display brightness (typical)
| 550 cd/m²
|
Response time
| 25 ms
|
HD type
| 4K DCI
|
Display technology
| LCD
|
LED backlight
| Y
|
Screen shape
| Flat screen
|
Contrast ratio (typical)
| 1800:1
|
Viewing angle, horizontal
| 178 °
|
Viewing angle, vertical
| 178 °
|
Display number of colours
| 1.07 billion colours
|
Display diagonal (metric)
| 77.5 cm
|
Pixel pitch
| 0.1674 x 0.1674 mm
|
Viewable size, horizontal
| 685.7 mm
|
Viewable size, vertical
| 361.6 mm
|
Digital horizontal frequency
| 31 - 134 kHz
|
Digital vertical frequency
| 59 - 61 Hz
|
Colour depth
| 13 Bit
|
Performance |
NVIDIA G-SYNC
| N
|
AMD FreeSync
| N
|
Multimedia |
Built-in speaker(s)
| N
|
Built-in camera
| N
|
Design |
Market positioning
| Medical
|
Product colour
| Black
|
Feet colour
| Black
|
Certification
| CE (Medical Device), UKCA (Medical Device), ANSI/AAMI ES60601-1, CSA C22.2 Nr. 601-1, EN60601-1, IEC60601-1, CB, RCM, FCC-B, CAN ICES-3 (B), VCCI-B, RoHS, WEEE, China RoHS, CCC
|
Ports & interfaces |
Built-in USB hub
| Y
|
USB upstream port type
| USB Type-B, USB Type-C
|
Number of USB Type-B upstream ports quantity
| 2
|
Number of USB Type-C upstream ports quantity
| 1
|
USB Type-A downstream ports quantity
| 3
|
USB Type-C downstream ports quantity
| 1
|
USB Type-C DisplayPort Alternate Mode
| Y
|
USB Power Delivery up to
| 94 W
|
HDMI
| Y
|
HDMI ports quantity
| 1
|
DisplayPorts quantity
| 1
|
Headphone out
| N
|
Built-in KVM switch
| Y
|
Ergonomics |
VESA mounting
| Y
|
Panel mounting interface
| 100 x 100 mm
|
Height adjustment
| Y
|
Height adjustment
| 100 mm
|
Swivelling
| Y
|
Tilt angle range
| 5 - 30 °
|
Tilt adjustment
| Y
|
On Screen Display (OSD)
| Y
|
On Screen Display (OSD) languages
| DEU, ENG, ESP, FRE, ITA, SWE
|
Packaging data |
Cables included
| AC, DisplayPort, HDMI, USB Type-A to USB Type-B, USB Type-C to USB Type-C
|
Quick start guide
| Y
|
Power |
Energy efficiency class (SDR)
| Not available
|
Power consumption (typical)
| 62 W
|
Energy efficiency class (HDR)
| Not available
|
Power consumption (standby)
| 0.5 W
|
Power consumption (max)
| 260 W
|
AC input voltage
| 100 - 240 V
|
AC input frequency
| 50/60 Hz
|
Weight & dimensions |
Width (with stand)
| 721 mm
|
Depth (with stand)
| 225.1 mm
|
Height (with stand)
| 469.5 mm
|
Weight (with stand)
| 12400 g
|
Width (without stand)
| 721 mm
|
Depth (without stand)
| 73 mm
|
Height (without stand)
| 401 mm
|
Weight (without stand)
| 8200 g
|
Other features |
USB Power Delivery
| Y
|
Touchscreen
| N
|
Manual
| Y
|
Ethernet LAN
| Y
|
