EnGenius Cloud Managed Layer 2+ Aggregate Switch, ECS5512F is a reliable and easy-to-manage 12-Port 10G SFP+ uplink ports switch that provides high-speed connectivity for your network devices. Its Zero-touch provisioning and centralized cloud management make it easy to set up and manage your network from anywhere, anytime. With its Voice-VLAN feature and robust security, you can ensure quality voice and video traffic while protecting against malicious attacks.

Specification

Product
Product id	987853
Brand	EnGenius
Partnr	ECS5512F
EAN/UPC code	4713361935978
Data transmission
MAC address table	32000 entries
Switching capacity	240 Gbit/s
Jumbo frames support	Y
Jumbo frames	9000
Network
Networking standards	IEEE 802.3ab, IEEE 802.3bz, IEEE 802.3u, IEEE 802.3x
Full duplex	Y
Flow control support	Y
Link aggregation	Y
VLAN support	Y
Management features
Switch type	Managed
Switch layer	L2+
Quality of Service (QoS) support	Y
Cloud-managed	Y
Web-based management	Y
Configuring Location Settings (CLI)	Y
System event log	Y
Ports & interfaces
Basic switching RJ-45 Ethernet ports type	N
SFP+ module slots quantity	12
Security
DHCP features	DHCP server, DHCPv6 client
Weight & dimensions
Width	210 mm
Depth	230 mm
Height	44 mm
Weight	1360 g
Packaging data
Package weight	5980 g
Package width	306 mm
Package depth	375 mm
Package height	149 mm
Power
Power source	AC
AC input voltage	100 - 240 V
AC input frequency	50/60 Hz
Multicast features
Multicast support	Y
Design
Rack mounting	Y
Product colour	Black
Operational conditions
Storage relative humidity (H-H)	5 - 90 procent
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 90 procent
Performance
Memory type	SDRAM
Internal memory	512 MB
Flash memory	128 MB
Power over Ethernet (PoE)
Power over Ethernet (PoE)	N
