Epson ELPDC13. Optical sensor size: 25.4 / 2.7 mm (1 / 2.7"), Sensor type: CMOS, Supported graphics resolutions: 1920 x 1080 (HD 1080). Digital zoom: 16x, Shooting area (WxD): 297 x 420 mm. Interface: USB 1.1, USB connector type: USB Type-B. Compatible memory cards: SD, Maximum memory card size: 32 GB. Power supply type: AC, Power consumption (typical): 13 W, Power consumption (standby): 0.5 W

Specification

Product
Product id	539649
Brand	Epson
Partnr	V12H757040
EAN/UPC code	8715946610115
Warranty (months)	12 months
Camera
Optical sensor size	1/2.7 "
Sensor type	CMOS
Supported graphics resolutions	1920 x 1080 (HD 1080)
Maximum frame rate	30 fps
White balance	Auto
Light exposure modes	Auto
Image freeze	Y
Light source	LED
Lens system
Auto focus	Y
Digital zoom	16 x
Shooting area (WxD)	297 x 420 mm
Ports & interfaces
Interface	USB 1.1
USB connector type	USB Type-B
VGA (D-Sub) input ports	1
VGA (D-Sub) output ports	1
DC-in jack	Y
Parallel connector	Y
Technical details
Document size (max)	A3
Product colour	White
Horizontal rotation angle	-90 - 90 °
Display modes	Microscope
Vertical rotation angle	-90 - 90 °
Split screen	Y
Zoom capability	Y
Image viewer	Y
Image quality adjustment	Brightness, Contrast
Illumination	Y
Country of origin	Philippines
Bundled software	Easy Interactive Tools, TWAIN-Treiber für Epson Dokumentenkamera (für Windows)
Lamp type	LED
Built-in microphone	Y
Cable lock slot	Y
Compatible operating systems	Mac OS 10.7. x, Mac OS 10.8. x, Mac OS 10.9. x, Mac OS X, Windows 10, Windows 7, Windows 8, Windows 8.1, Windows Vista
Cable lock slot type	Kensington
Output resolutions	SXGA (1280*1024)/XGA (1024*768)/WXGA 16:10 (1280*800)/WXGA 16:9 (1360*768)/1080p (1920*1080), 480p/720p/1080p
Photo effects	Black&White
Storage
Card reader integrated	Y
Compatible memory cards	SD
Maximum memory card size	32 GB
Power
Power supply type	AC
Power consumption (typical)	13 W
Power consumption (standby)	0.5 W
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Weight & dimensions
Width	270 mm
Depth	317 mm
Height	447 mm
Weight	2500 g
System requirements
Windows operating systems supported	Windows 10, Windows 7, Windows 8, Windows 8.1, Windows Vista
Mac compatibility	Y
Mac operating systems supported	Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Operational conditions
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	20 - 80 procent
Packaging content
AC adapter included	Y
Manual	Y
Carrying case	Y
Software CD	Y
Cables included	AC
Packaging data
Quantity per pack	1 stuk(s)
Package width	235 mm
Package depth	445 mm
Package height	180 mm
Package weight	4580 g
Logistics data
Quantity per pallet	66 stuk(s)
Pallet width (UK)	1000 mm
Pallet length (UK)	1200 mm
Quantity per pallet (UK)	110 stuk(s)
Quantity per pallet layer (UK)	10 stuk(s)
Quantity per pallet layer	6 stuk(s)
Pallet height	5045 mm
Pallet width	800 mm
Pallet length	1200 mm
Pallet height (UK)	5045 mm
