The new FUJITSU USB Port Replicator PR09 is the perfect solution for shared desk environments within a hyperconnected world. It connects your mobile system to your main peripherals with a single USB plug. This Port Replicator is equipped with the most powerful DisplayLink chipset supporting high performance video streaming with Dualhead-DisplayPort.
Highest data throughput is guaranteed due to an USB Type-C based Gen2 Hub-Controller enabling up to 10Gbit/s data streaming. The newest version of USB Power Delivery chipset (PD3.0) provides powerful charging during your workday.

Specification

Product
Product id	596351
Brand	Fujitsu Technology Solutions
Partnr	S26391-F6007-L500
EAN/UPC code	4057185642316
Ports & interfaces
Connectivity technology	Wired
Host interface	USB 3.2 Gen 1 (3.1 Gen 1) Type-C
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	4
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity	4
DisplayPorts quantity	2
S/PDIF out port	Y
DC-in jack	Y
Network
Ethernet LAN	Y
Ethernet LAN (RJ-45) ports	1
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Performance
Product colour	Black
Card reader integrated	N
Cable lock slot	Y
Cable lock slot type	Kensington
Brand compatibility	Fujitsu
LED indicators	Y
Power
Power source type	AC, DC
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power supply type	External
Output current	6 A
Output voltage	20 V
Power consumption (max)	120 W
Power consumption (typical)	82 W
Software
Windows operating systems supported	Y
Weight & dimensions
Width	200 mm
Depth	97.6 mm
Height	29 mm
Weight	340 g
Packaging content
Quick start guide	Y
AC adapter included	Y
Cables included	AC, USB Type-C
Operational conditions
Operating temperature (T-T)	5 - 35 °C
Storage temperature (T-T)	5 - 45 °C
Operating relative humidity (H-H)	10 - 85 procent
Technical details
Sustainability certificates	RoHS
