BOOST YOUR PRODUCTIVITY
Workload optimized performance for space and power constrained environments from the edge to the data center.

SCALE YOUR IT ACCORDING TO YOUR NEEDS
The PRIMERGY RX1330 M5 delivers the flexibility to increase compute, storage, and memory capacity based on various configuration options and different base units.

SIMPLIFY YOUR IT
New iRMC S6 enhances server administrator productivity with a variety of user-friendly features for remote management. Moreover, Infrastructure Manager (ISM) enables organizations to have centralized control over the entire infrastructure using a single user interface.

GROW YOUR BUSINESS
The variety of expansion options makes the RX1330 M5 an ideal rack server platform for growing businesses. Outstanding configuration flexibility caters to a variety of business requirements and a range of HPE Qualified Options to fit most needs.

Specification

Product
Product id	968052
Brand	Fujitsu Technology Solutions
Partnr	VFYR1335SX340IN
EAN/UPC code	4066733291494
Processor
Processor manufacturer	Intel
Processor family	Intel Xeon E
Processor model	E-2374G
Processor frequency	3.7 GHz
Processor boost frequency	5 GHz
Processor cores	4
Processor cache	8 MB
Motherboard chipset	Intel C256
Number of processors installed	1
Memory
Internal memory type	DDR4-SDRAM
ECC	Y
Memory clock speed	3200 MHz
Memory slots	4x DIMM
Maximum internal memory	128 GB
Storage
RAID support	Y
RAID levels	0, 1, 5, 6
Graphics
On-board graphics adapter	Y
On-board graphics adapter model	Intel UHD Graphics P750
On-board graphics adapter family	Intel UHD Graphics
Network
LAN controller	Intel I210
Ethernet LAN	Y
Cabling technology	10/100/1000Base-T(X)
Ethernet interface type	Gigabit Ethernet
Ports & interfaces
Ethernet LAN (RJ-45) ports	2
USB 2.0 ports quantity	2
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	4
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity	1
VGA (D-Sub) ports quantity	1
Expansion slots
PCI Express x4 (Gen 3. x) slots	1
PCI Express x8 (Gen 4. x) slots	2
PCI slots	1
Design
Chassis type	Rack
Product colour	Black, Stainless steel
Rack mounting	Y
Bezel	Y
Performance
Noise level	22 dB
Trusted Platform Module (TPM) version	2.0
Trusted Platform Module (TPM)	Y
BIOS type	UEFI
Software
Operating system installed	N
Compatible operating systems	Windows Server 2022 Datacenter, Windows Server 2022 Standard, Windows Server 2022 Essentials, Windows Server 2019 Datacenter, Windows Server 2019 Standard, Windows Server 2019 Essentials, VMware vSphere 7.0, Red Hat Enterprise Linux 8
Power
Redundant power supply (RPS) support	Y
Power supply	500 W
Number of main power supplies	1
Power supply input voltage	100 - 240
Power supply input frequency	50 / 60 Hz
Operational conditions
Operating temperature (T-T)	5 - 45 °C
Operating relative humidity (H-H)	10 - 85 procent
Certificates
Certification	CB, GS, CE, NRTLc/us, FCC, ICES-003, NMB-003, VCCI, JIS 61000-3-2, EAC, KC, CCC, RCM, BSMI
Weight & dimensions
Width	482.6 mm
Depth	612 mm
Height	43 mm
Weight	13000 g
Technical details
Sustainability compliance	Y
Compliance certificates	RoHS, WEEE
