AMD EPYC™ 7002 Series Processor (Rome)
The next generation of AMD EPYC has arrived, providing incredible compute, IO and bandwidth capability – designed to meet the huge demand for more compute in big data analytics, HPC and cloud computing.

Specification

Product
Product id	841114
Brand	Gigabyte
Partnr	6NG292Z20MR-00
EAN/UPC code	4719331600099
Processor
Built-in processor	N
Motherboard chipset	AMD SoC
Processor socket	Socket SP3
Number of processors supported	1
Compatible processor series	AMD EPYC 7002
Memory
Number of DIMM slots	8
Supported memory types	DDR4-SDRAM
Maximum RDIMM memory	128 GB
Memory channels	Octa-channel
Storage
Number of storage drives supported	8
Hot-swap HDD bays	Y
Number of 2.5" bays	8
Storage drive sizes supported	2.5, M.2 "
Supported storage drive types	HDD & SSD
Supported storage drive interfaces	PCI Express 3.0, Serial ATA, Serial Attached SCSI (SAS)
SSD form factor	M.2
Graphics
On-board graphics adapter model	Aspeed AST2500
Network
Ethernet LAN	Y
Ethernet interface type	Gigabit Ethernet, 10 Gigabit Ethernet
Ethernet LAN data rates	10, 100, 1000, 10000 Mbit/s
LAN controller	Mellanox ConnectX-4 Lx
Ports & interfaces
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	2
VGA (D-Sub) ports quantity	1
SFP+ module slots quantity	2
Expansion slots
PCI Express x16 (Gen 4. x) slots	10
Number of M.2 (M) slots	1
Features
Trusted Platform Module (TPM)	Y
Backplanes support	Y
Compatible operating systems	Windows Server 2016 (X2APIC/256T not supported); Windows Server 2019; Red Hat Enterprise Linux 7.6 or later; Red Hat Enterprise Linux 8.0 or later; Red Hat Enterprise Linux 9.0 or later; SUSE Linux Enterprise Server 12 SP4 or later; SUSE Linux Enterprise Server 15 SP1 or later; Ubuntu 16.04.6 LTS or later; Ubuntu 18.04.3 LTS or later; Ubuntu 20.04 LTS or later; VMware ESXi 6.5 EP15 or later; VMware ESXi 6.7 Update3 or later; VMware ESXi 7.0 or later; VMware ESXi 8.0 or later; Citrix Hypervisor 8.1.0 or later
Design
Chassis type	Rack (2U)
Product colour	Black, Steel
LED indicators	LAN, HDD, Status
On/off switch	Y
Reset button	Y
Cooling type	Active
Heat sink included	Y
Number of fans	8 ventilator(en)
Fan diameter	80 mm
Power
Power supply	2200 W
Number of main power supplies	2
Redundant power supply (RPS) support	Y
Number of redundant power supplies supported	2
Number of redundant power supplies installed	2
AC input voltage	100 - 240 V
AC input frequency	50/60 Hz
Input current	12.6 - 14 A
80 PLUS certification	80 PLUS Platinum
Operational conditions
Operating temperature (T-T)	10 - 35 °C
Storage temperature (T-T)	-40 - 60 °C
Operating relative humidity (H-H)	8 - 80 procent
Storage relative humidity (H-H)	20 - 95 procent
Weight & dimensions
Width	448 mm
Depth	800 mm
Height	87.5 mm
Packaging data
Packaging content	1 x G292-Z20; 1 x CPU heatsink; 1 x L-shape Rail kit
Package width	1133 mm
Package depth	724 mm
Package height	261 mm
Package weight	34090 g
