AMD Barebone G492-Z50 4U 2xCPU 32xDIMM 12xHDD 10xPCIe 3x2200W



Gigabyte
Not in stock
€ 7.254,42
€ 8.777,84 incl 21% VAT
The next generation of AMD EPYC has arrived, providing incredible compute, IO and bandwidth capability – designed to meet the huge demand for more compute in big data analytics, HPC and cloud computing.

Built on 7nm advanced process technology, allowing for denser compute capabilities with lower power consumption
Up to 64 core per CPU, built using Zen 2 high performance cores and AMD’s innovative chiplet architecture
Supporting PCIe® 4.0 with a bandwidth of up to 64GB/s, twice of PCIe 3.0
Embedded security protection to help defend your CPU, applications, and data

High Density HPC
Supports 10 x PCIe® 4.0 Computing Cards
The G492-Z50 can support ten PCIe® 4.0 GPGPU cards in balanced mode, with each five GPU cards connected to one CPU downstream via a PCIe switch to minimize GPU to GPU communication latency.

PCIe® 4.0 Ready
AMD EPYC Rome is ready to support PCIe® 4.0 with a bandwidth of 64GB/s, twice that of PCIe 3.0. This doubles the bandwidth available from the CPU to peripheral devices such as graphics cards, storage devices and high speed network cards. GIGABYTE’s AMD EPYC 7002 Series server platforms are ready to be used with a new generation of PCIe 4.0 devices such as AMD’s Radeon MI50 GPGPU.

Higher Memory Speed
AMD EPYC’s Rome 7002 Series processors feature faster 8 channel DDR4 memory lanes, supporting RDIMM or LRDIMM memory modules with a speed of up to 3200MHz (1 DIMM per channel)

Specification

Product
Product id 841096
Brand Gigabyte
Partnr 6NG492Z50MR-00
EAN/UPC code 4719331600044
Processor
Processor socket Socket SP3
Processor manufacturer AMD
Processor family AMD EPYC
Number of processors supported 2
Memory
Number of DIMM slots 32
Supported memory types DDR4-SDRAM
Supported RDIMM clock speeds 2933, 3200 MHz
Supported UDIMM clock speeds 3200 MHz
Storage
Number of storage drives supported 12
Hot-swap HDD bays Y
Number of 3.5" bays 12
Storage drive sizes supported 3.5 "
Supported storage drive interfaces Serial ATA III, Serial Attached SCSI (SAS)
Ports & interfaces
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity 2
Ethernet LAN (RJ-45) ports 3
VGA (D-Sub) ports quantity 1
Expansion slots
PCI Express x16 slots 13
Features
Compatible operating systems Windows Server 2016 (X2APIC/256T not supported) Windows Server 2019 Red Hat Enterprise Linux 7.6 ( x64) or later Red Hat Enterprise Linux 8.0 ( x64) or later Red Hat Enterprise Linux 9.0 (x64) or later SUSE Linux Enterprise Server 12 SP4 ( x64) or later SUSE Linux Enterprise Server 15 SP1 ( x64) or later Ubuntu 16.04.6 LTS (x64) or later Ubuntu 18.04.3 LTS (x64) or later Ubuntu 20.04 LTS (x64) or later VMware ESXi 6.5 EP15 or later VMware ESXi 6.7 Update3 or later VMware ESXi 7.0 or later VMware ESXi 8.0 or later Citrix Hypervisor 8.1.0 or later
Design
Number of fans 16 ventilator(en)
Power
Power supply 2200 W
Number of main power supplies 3
Redundant power supply (RPS) support Y
Number of redundant power supplies supported 3
Number of redundant power supplies installed 3
AC input voltage 200 - 240 V
DC output current (+12 V) 178 A
Operational conditions
Operating temperature (T-T) 10 - 35 °C
Storage temperature (T-T) -40 - 60 °C
Operating relative humidity (H-H) 10 - 35 procent
Storage relative humidity (H-H) 20 - 95 procent
Weight & dimensions
Width 448 mm
Depth 880 mm
Height 176 mm
Packaging data
Package width 1109 mm
Package depth 609 mm
Package height 606 mm
