AMD EPYC™ 7003 Series Processors
GIGABYTE servers and AMD EPYC 7003 Series Processors deliver the highest possible I/O throughput to pave the way for fast communication between CPU and accelerator in HPC and data analytics.

Specification

Product
Product id	841135
Brand	Gigabyte
Partnr	6NR262ZA0MR-00
EAN/UPC code	4719331600297
Processor
Built-in processor	N
Compatible processor series	AMD EPYC 7003, AMD EPYC 7002
Memory
Number of DIMM slots	16
Supported memory types	GDDR5
Memory channels	Octa-channel
Storage
Number of storage drives supported	43
Hot-swap HDD bays	Y
Storage drive sizes supported	2.5, M.2 "
Supported storage drive types	HDD & SSD
Supported storage drive interfaces	Serial ATA, PCI Express 4.0
Graphics
On-board graphics adapter model	Aspeed AST2520
Network
Ethernet LAN	Y
Ethernet interface type	Gigabit Ethernet
Ethernet LAN data rates	10, 100, 1000 Mbit/s
LAN controller	Intel I350-AM2
Ports & interfaces
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	4
Ethernet LAN (RJ-45) ports	2
VGA (D-Sub) ports quantity	1
Mini DisplayPorts quantity	1
Expansion slots
PCI Express slots version	4.0
Number of M.2 (M) slots	1
Features
Trusted Platform Module (TPM)	Y
Design
Chassis type	Rack (2U)
Product colour	Black, Steel
LED indicators	HDD, LAN, Status
On/off switch	Y
Reset button	Y
Cooling type	Active
Number of fans	4 ventilator(en)
Fan diameter	80 mm
Power
Power supply	1200 W
Number of main power supplies	2
Redundant power supply (RPS) support	Y
Number of redundant power supplies supported	1
AC input voltage	100 - 240 V
AC input frequency	47 - 63 Hz
Input current	12.47 - 7.08 A
80 PLUS certification	80 PLUS Platinum
Operational conditions
Operating temperature (T-T)	10 - 35 °C
Storage temperature (T-T)	-40 - 60 °C
Operating relative humidity (H-H)	8 - 80 procent
Storage relative humidity (H-H)	20 - 95 procent
Weight & dimensions
Width	438 mm
Depth	730 mm
Height	87.5 mm
Weight	21600 g
Packaging data
Packaging content	1 x R262-ZA0 1 x CPU heatsink 1 x 2-Section Rail kit
Package width	982 mm
Package depth	588 mm
Package height	268 mm
Package weight	32000 g
