Ampere® Altra® Max Processor
Cloud Native Server Processors
Ampere’s Altra® family of processors are designed to deliver on predictable performance, high scalability and power efficiency. Ampere’s leadership on all these metrics deliver exceptional results and lower the TCO for Cloud Service Providers.

Performance Boost
Up to 80 /128 cores and 128 PCIe lanes demand data to be processed quickly and more jobs at the same time.

Architecture Efficiency
Designed for Cloud and Edge (cloud ecosystem native platform) and provides a high number of computing cores, faster throughput, and low power consumption.

Aggregate Powerhouse
Provides a management tool for cloud and edge to simplify management and improve efficiency.

Superhighway of Data
Utilizing the latest in PCIe 4.0 and 128 PCIe lanes allows faster throughput in GPUs, storage and networking.

Green Savings
Best in class performance/watt, Ampere® Altra® continues to increase value while driving down TCO.

Cooperation
GIGABYTE has developed with Arm systems for almost 10 years. Servers will be ready with fast TTM and product offerings.

Specification

Product
Product id	883949
Brand	Gigabyte
Partnr	6NR282P92DR-00
EAN/UPC code	4719331601683
Processor
Built-in processor	N
Processor socket	LGA 4926
Number of processors supported	2
Memory
Number of DIMM slots	32
Supported memory types	DDR4-SDRAM
Maximum RDIMM memory	256 GB
Supported RDIMM clock speeds	2933, 3200 MHz
Storage
Number of storage drives supported	6
Hot-swap HDD bays	Y
Number of 2.5" bays	6
Number of 3.5" bays	6
Storage drive sizes supported	2.5, 3.5 "
Supported storage drive types	HDD & SSD
Supported storage drive interfaces	Serial ATA, Serial Attached SCSI (SAS)
Graphics
On-board graphics adapter model	Aspeed AST2500
Network
Ethernet LAN	Y
Ethernet LAN data rates	10, 100, 1000 Mbit/s
LAN controller	Intel I350-AM2
Ports & interfaces
Ethernet LAN (RJ-45) ports	2
VGA (D-Sub) ports quantity	1
COM ports quantity	1
Expansion slots
PCI Express slots version	4.0
PCI slots	7
PCI Express x24 Riser Super slots	1
Number of M.2 (M) slots	1
Features
Trusted Platform Module (TPM)	Y
Trusted Platform Module (TPM) version	2.0
Backplanes support	Y
Harmonized System (HS) code	84714100
Compatible operating systems	Windows Server 2016 ( X2APIC/256T not supported) Windows Server 2019 Red Hat Enterprise Linux 8.3 ( x64) or later SUSE Linux Enterprise Server 12 SP5 ( x64) or later SUSE Linux Enterprise Server 15 SP2 ( x64) or later Ubuntu 18.04.5 LTS (x64) or later Ubuntu 20.04 LTS (x64) or later VMware ESXi 6.7 Update3 P03 or later VMware ESXi 7.0 Update1 or later Citrix Hypervisor 8.2.0 or later
Design
Chassis type	Rack (2U)
LED indicators	HDD, LAN, Status
Power
Power supply	2000 W
Number of main power supplies	2
Redundant power supply (RPS) support	Y
AC input voltage	110 - 240 V
DC output current (+5 V)	81 A
DC output current (+12 V)	163 A
Operational conditions
Operating temperature (T-T)	10 - 35 °C
Storage temperature (T-T)	-40 - 60 °C
Operating relative humidity (H-H)	8 - 80 procent
Storage relative humidity (H-H)	20 - 95 procent
Weight & dimensions
Width	438 mm
Depth	87 mm
Height	730 mm
Packaging data
Packaging content	1 x R282-Z96 system 2 x CPU heatsinks 1 x Rail kit
Package width	982 mm
Package depth	588 mm
Package height	268 mm
