80 PLUS
SILVER CERTIFIED
The 80 Plus Silver certification (230V EU) guarantees a 90% efficiency rate at a 50% load, resulting in reduced power wastage, diminished heat generation, and minimized fan noise.

Support Intel
ATX 3.0 standard
The P550SS can sustain up to 2x total power excursion. It is fully compatible with Intel PSDG (Power Supply Design Guide) ATX 3.0 standard which supports up to 200% power excursion, reaches 70% low load efficiency and complies with required power supply timing standards.

120MM FLUID DYNAMIC
BEARING(FDB) FAN
High-performance Fluid Dynamic Bearing fan uses oil film shock absorption technology to effectively reduce noise, making it quieter than conventional sleeve fan and providing more than twice the lifespan. In addition, the fan will detect the current power usage and temperature, automatically adjust the fan speed to minimize the noise.

RELIABLE FLAT CABLE DESIGN
The utilization of flat cables minimizes clutter while enhancing the thermal performance of the chassis.

SINGLE +12V RAIL
The single +12V rail delivers optimal power output, stability, and hardware compatibility. This design not only simplifies power cable installation but also stands as the most effective choice for overclocking purposes.

PROTECTION
To guarantee the stable operation of your entire computer system under any circumstances, we have incorporated a range of protective features including OCP, OTP, OVP, OPP, UVP, and SCP. Moreover, we have obtained safety certifications from various countries to ensure the consistent and secure functioning of your system.

Specification

Product
Product id	985824
Brand	Gigabyte
Partnr	GP-P550SS
EAN/UPC code	4719331554187
Warranty (months)	3 years
Endurance
Mean time between failures (MTBF)	100000 uur
Power
Total power	550 W
AC input voltage	155-240 V
AC input frequency	50/60 Hz
Input current	6.3 A
Power factor	0.9
Power Factor Correction (PFC) type	Active
Combined power (+3.3V)	100 W
Combined power (+12V)	549.6 W
Combined power (+5V)	200 W
Combined power (-12V)	3.6 W
Combined power (+5Vsb)	15 W
Max output current (+3.3V)	20 A
Max output current (+12V)	45.8 A
Max output current (+5V)	20 A
Max output current (-12V)	0.3 A
Max output current (+5Vsb)	3 A
Efficiency	90 procent
Hold time	16 ms
Power protection features	Over current, Over power, Over voltage, Overheating, Short circuit, Under voltage
Ports & interfaces
Motherboard power connector	20+4 pin ATX
Motherboard power cable length	600 mm
Number of SATA power connectors	5
SATA power cable length	500 mm
Peripheral (Molex) power connectors (4-pin)	3
Peripheral (Molex) power cable length	500 mm
PCI Express power connectors (6+2 pin)	2
PCI Express power cable length	500 mm
CPU power connector (4+4 pin)	Y
CPU power cable length	600 mm
ATX power connector (20+4 pin)	Y
Floppy disk drive connector	Y
Floppy drive power connector	1
PCI Express connector	Y
Cabling type	Non-Modular
Performance
Purpose	PC
Power supply unit (PSU) form factor	ATX
80 PLUS certification	80 PLUS Bronze
ATX version	3.0
Bearing technology	HDB
Design
Product colour	Black
Cooling type	Active
Fan diameter	120 mm
Number of fans	1 ventilator(en)
Fan location	Top
On/off switch	Y
Weight & dimensions
Width	150 mm
Depth	140 mm
Height	86 mm
Other features
Harmonized System (HS) code	84733020
