The black flat cable reduces the clutter and improves the chassis thermal performance.

80 PLUS GOLD CERTIFIED
80 Plus Gold certified ensures to deliver 90% efficiency at 50% load. The better power efficiency leads to less power waste, less heat and less fan noise.

HIGH QUALITY JAPANESE CAPACITORS
The main capacitors are high quality Japanese capacitors, to produce the efficient performance and to ensure the longer reliability.

120MM SMART HYDRAULIC BEARING (HYB) FAN
The fan speed is adjusted according to the automatic power detection. The Hydraulic Bearing fan provides longer and more stable life time.

SINGLE +12V RAIL
Single +12V rail provides the best power output, stability and compatibility for the hardware. It provides the easiest way to install the power cable. And it is the best design for overclocking.

PROTECTION
In order to make sure the entire computer system to operate stably under any conditions, we not only added protection designs such as OCP, OTP, OVP, OPP, UVP and SCP, but also ensured the stable operation of your system through the safety certification of various countries.

DIMENSIONS
Compact size to fit any small chassis.

Specification

Product
Product id	985821
Brand	Gigabyte
Partnr	GP-P650G
EAN/UPC code	4719331553753
Warranty (months)	3 year
Sound emission
Noise level	39 dB
Endurance
Mean time between failures (MTBF)	100000 uur
Power
Total power	650 W
AC input voltage	100 - 240 V
Input current	12 - 6 A
Maximum input current (@110V)	12 A
Maximum input current (@220V)	6 A
Power Factor Correction (PFC) type	Active
Combined power (+3.3V)	120 W
Combined power (+12V)	650 W
Combined power (+5V)	650 W
Combined power (-12V)	3.6 W
Combined power (+5Vsb)	12.5 W
Max output current (+3.3V)	20 A
Max output current (+12V)	54.17 A
Max output current (+5V)	20 A
Max output current (-12V)	0.3 A
Max output current (+5Vsb)	20 A
Power protection features	Over power, Overcharge, Short circuit, Under voltage
Ports & interfaces
Motherboard power connector	20+4 pin ATX
Motherboard power cable length	500 mm
Number of SATA power connectors	6
SATA power cable length	150, 500 mm
Peripheral (Molex) power connectors (4-pin)	3
Peripheral (Molex) power cable length	150, 500 mm
PCI Express power connectors (6+2 pin)	4
PCI Express power cable length	650 mm
CPU P4 connector (4-pin)	1
CPU power connector (4+4 pin)	Y
CPU power cable length	600 mm
ATX power connector (20+4 pin)	Y
Floppy disk drive connector	Y
Cabling type	Non-Modular
Performance
Purpose	PC
Power supply unit (PSU) form factor	ATX
80 PLUS certification	80 PLUS Bronze
ATX version	2.31
Bearing technology	HDB
Design
Product colour	Black
Cooling type	Active
Fan diameter	120 mm
Number of fans	1 ventilator(en)
Fan location	Top
On/off switch	Y
Weight & dimensions
Width	140 mm
Depth	150 mm
Height	86 mm
Packaging data
Package type	Box
