Ensure reliable and efficient power delivery with GIGABYTE power supplies. Designed for peak performance and durability, our PSUs offer stable and consistent energy to power your high-performance systems. With advanced protections and high-quality components, GIGABYTE power supplies provide the confidence you need for seamless, uninterrupted computing experiences.

Specification

Product
Product id	985823
Brand	Gigabyte
Partnr	GP-P650SS ICE
EAN/UPC code
Warranty (months)	3 years
Endurance
Mean time between failures (MTBF)	100000 uur
Power
Total power	650 W
AC input voltage	155-240 V
AC input frequency	50/60 Hz
Input current	6.3 A
Power factor	0.9
Power Factor Correction (PFC) type	Active
Combined power (+3.3V)	100 W
Combined power (+12V)	649.2 W
Combined power (+5V)	100 W
Combined power (-12V)	3.6 W
Combined power (+5Vsb)	15 W
Max output current (+3.3V)	20 A
Max output current (+12V)	54.1 A
Max output current (+5V)	20 A
Max output current (-12V)	0.3 A
Max output current (+5Vsb)	3 A
Power Good signal delay range	100 - 150 ms
Power protection features	Over power, Overcharge, Short circuit, Under voltage
Ports & interfaces
Motherboard power connector	20+4 pin ATX
Motherboard power cable length	600 mm
Number of SATA power connectors	5
SATA power cable length	120, 500 mm
Peripheral (Molex) power connectors (4-pin)	2
Peripheral (Molex) power cable length	120, 500 mm
PCI Express power connectors (6+2 pin)	2
PCI Express power cable length	650 mm
CPU P4 connector (4-pin)	1
CPU power connector (4+4 pin)	Y
CPU power cable length	600 mm
ATX power connector (20+4 pin)	Y
Floppy disk drive connector	Y
Cabling type	Non-Modular
Performance
Purpose	PC
Power supply unit (PSU) form factor	ATX
80 PLUS certification	80 PLUS Silver
ATX version	3.0
Bearing technology	FDB
Design
Product colour	White
Cooling type	Active
Fan diameter	120 mm
Number of fans	1 ventilator(en)
Fan location	Top
On/off switch	Y
Technical details
Warranty period	3 jaar
Weight & dimensions
Width	140 mm
Depth	150 mm
Height	86 mm
Weight	2230 g
Packaging data
Package width	254 mm
Package depth	206 mm
Package height	117 mm
Package weight	2600 g
Package type	Box
