Elevate your computing experience with GIGABYTE's renowned motherboard series: AORUS, AERO, and GIGABYTE. Featuring innovative designs and advanced features, these boards offer exceptional performance and reliability. Whether you're a gamer, content creator, or professional, our series cater to your needs, ensuring uncompromising quality and cutting-edge

Specification

Product
Product id	985898
Brand	Gigabyte
Partnr	TRX50 AI TOP
EAN/UPC code	4719331868529
Warranty (months)	3 years
Processor
Processor manufacturer	AMD
Processor socket	Socket sTR5
Compatible processor series	AMD Ryzen Threadripper 7000 Series, AMD Ryzen Threadripper PRO 7000 WX-Series
Supported processor sockets	sTRX5
Maximum internal memory supported by processor	2000 GB
Memory
Supported memory types	DDR5-SDRAM
Number of memory slots	8
Memory slots type	DIMM
Memory channels	Quad-channel
ECC сompatibility	ECC
Maximum internal memory	2000 GB
Unbuffered memory	Y
Storage controllers
Supported storage drive types	HDD & SSD
Supported storage drive interfaces	M.2, SATA III
Number of HDDs supported	4
Number of storage drives supported	8
RAID levels	0, 1, 10
RAID support	Y
Graphics
Maximum resolution	4096 x 2160 Pixels
HDCP	Y
DirectX version	12.0
Internal I/O
USB 2.0 connectors	2
USB 3.2 Gen 1 (3.1 Gen 1) connectors	1
Number of SATA III connectors	4
Total number of SATA connectors	4
Front panel audio connector	Y
Front panel connector	Y
ATX Power connector (24-pin)	Y
Power fan connector	Y
CPU fan connector	Y
EPS power connector (8-pin)	Y
Serial port headers	1
TPM connector	Y
RGB LED pin header	Y
Rear panel I/O ports
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity	6
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity	2
Ethernet LAN (RJ-45) ports	1
Network
Ethernet LAN	Y
Ethernet interface type	10 Gigabit Ethernet
Wi-Fi	Y
Top Wi-Fi standard	Wi-Fi 7 (802.11be)
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax), Wi-Fi 7 (802.11be)
Bluetooth	Y
Bluetooth version	5.3
Features
Component for	PC
Motherboard form factor	Extended ATX
Motherboard chipset family	AMD
Motherboard chipset	AMD TRX50
Audio chip	Realtek ALC4080
Audio output channels	2.0 kanalen
PC health monitoring	FAN, Temperature, Voltage
Linux operating systems supported	Ubuntu 24.04 LTS
Windows operating systems supported	Windows 11
Expansion slots
PCI Express x16 slots	3
Number of M.2 (M) slots	4
BIOS
BIOS type	UEFI AMI
BIOS memory size	256 Mbit
ACPI version	5.0
Clear CMOS jumper	Y
Desktop Management Interface (DMI) version	2.7
System Management BIOS (SMBIOS) version	2.7
Packaging data
Package width	379 mm
Package depth	397 mm
Package height	105 mm
Battery
Battery weight	3 g
Lithium weight per battery	0.07 g
Number of battery cells	1
Battery technology	Lithium-Manganese Dioxide (LiMnO2)
Battery type	CR2032
Logistics data
Country of origin	Taiwan
Quantity per shipping (inner) case	1 stuk(s)
Weight & dimensions
Width	305 mm
Depth	330 mm
Height	35 mm
Packaging content
Batteries included	Y
Bundled software	Norton® Internet Security (OEM version) LAN bandwidth management software
Technical details
Warranty period	3 jaar
Other features
Package weight	6470 g
