Elevate your computing experience with GIGABYTE's renowned motherboard series: AORUS, AERO, and GIGABYTE. Featuring innovative designs and advanced features, these boards offer exceptional performance and reliability. Whether you're a gamer, content creator, or professional, our series cater to your needs, ensuring uncompromising quality and cutting-edge

Specification

Product
Product id	985937
Brand	Gigabyte
Partnr	W790 AI TOP
EAN/UPC code	4719331866556
Warranty (months)	3 years
Processor
Processor manufacturer	Intel
Processor socket	LGA 4677 (Socket E)
Compatible processor series	Intel Xeon
Intel Xeon series	W-2400, W-3400, W3500, W-2500
Memory
Supported memory types	DDR5-SDRAM
Number of memory slots	8
Memory slots type	DIMM
Memory channels	Octa-channel
ECC сompatibility	ECC
Supported memory clock speeds	4800, 5600 MHz
Maximum internal memory	2000 GB
Supported memory clock speed (max)	5600 MHz
Maximum RDIMM memory	256 GB
Storage controllers
Supported storage drive types	HDD & SSD
Supported storage drive interfaces	M.2, SATA III
Number of HDDs supported	8
Number of storage drives supported	14
RAID levels	0, 1, 5, 10
RAID support	Y
Graphics
Parallel processing technology support	Not supported
Internal I/O
USB 2.0 connectors	2
USB 3.2 Gen 1 (3.1 Gen 1) connectors	1
USB 3.2 Gen 2x2 connectors	1
Number of SATA III connectors	8
Audio connector	Y
Front panel audio connector	Y
ATX Power connector (24-pin)	Y
CPU fan connector	Y
Number of chassis fan connectors	6
Number of CPU fan connectors	2
EPS power connector (8-pin)	Y
Number of EPS power connectors (8-pin)	4
TPM connector	Y
Number of water pump connectors	1
RGB LED pin header	Y
Number of temperature sensor headers	2
Number of RGB LED pin headers	4
Rear panel I/O ports
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	4
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity	2
Ethernet LAN (RJ-45) ports	2
DisplayPorts quantity	2
Headphone outputs	1
S/PDIF out port	Y
Line-in	Y
Digital audio optical out	1
Thunderbolt ports quantity	2
WiFi-AP antenna jack	2
Network
Ethernet LAN	Y
Ethernet interface type	10 Gigabit Ethernet
LAN controller	Intel X710-AT2
Wi-Fi	Y
Top Wi-Fi standard	Wi-Fi 7 (802.11be)
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax), Wi-Fi 6E (802.11ax), Wi-Fi 7 (802.11be)
WLAN controller model	Intel Wi-Fi 7 BE200
Bluetooth	Y
Bluetooth version	5.4
Features
Component for	Server
Motherboard form factor	Extended ATX
Motherboard chipset family	Intel
Motherboard chipset	Intel W790
Audio chip	Realtek ALC897
Audio output channels	7.1 kanalen
PC health monitoring	FAN, Temperature, Voltage, Water cooling
Product colour	Black
Power source type	ATX
Windows operating systems supported	Windows 11 x64
Expansion slots
PCI Express x16 (Gen 5. x) slots	5
Number of M.2 (M) slots	6
1st M.2 largest key size	2280
1st M.2 highest PCI Express generation	5.0
2nd M.2 largest key size	2280
2nd M.2 highest PCI Express generation	5.0
3rd M.2 largest key size	2280
3rd M.2 highest PCI Express generation	5.0
4th M.2 largest key size	2280
4th M.2 highest PCI Express generation	5.0
5th M.2 largest key size	2280
5th M.2 highest PCI Express generation	4.0
6th M.2 largest key size	2280
6th M.2 highest PCI Express generation	4.0
BIOS
BIOS type	UEFI AMI
BIOS memory size	512 Mbit
ACPI version	5.0
Clear CMOS jumper	Y
Desktop Management Interface (DMI) version	2.7
System Management BIOS (SMBIOS) version	2.7
Processor special features
Trusted Platform Module (TPM)	Y
Packaging data
Package width	363 mm
Package depth	383 mm
Package height	93 mm
Battery
Battery weight	3 g
Lithium weight per battery	0.07 g
Number of battery cells	1
Battery technology	Lithium-Manganese Dioxide (LiMnO2)
Battery type	CR2032
Logistics data
Country of origin	Taiwan
Quantity per shipping (inner) case	1 stuk(s)
Weight & dimensions
Width	305 mm
Depth	330 mm
Height	35 mm
Packaging content
Batteries included	Y
Screws included	Y
Antenna included	Y
Bundled software	Norton® Internet Security (OEM version) LAN bandwidth management software
Technical details
Warranty period	3 jaar
Other features
Weight	4870 g
Package weight	5700 g
