Specification

Product
Product id	1010138
Brand	Gigabyte
Partnr	X870 A STEALTH ICE
EAN/UPC code	4719331873097
Warranty (months)	3 years
Processor
Processor manufacturer	AMD
Processor socket	Socket AM5
Compatible processor series	AMD Ryzen 7000 Series, AMD Ryzen 8000 Series, AMD Ryzen 9000 Series
Supported processor sockets	Socket AM5
Memory
Supported memory types	DDR5-SDRAM
Number of memory slots	4
Memory slots type	DIMM
Memory channels	Dual-channel
ECC сompatibility	non-ECC
Supported memory clock speeds	8200, 8000, 7950, 7900, 7800, 7600, 7400, 7200, 7000, 6800, 6600, 6400, 6200, 6000, 5800, 5600, 5200, 4800, 4400 MHz
Maximum internal memory	256 GB
Supported memory clock speed (max)	8200 MHz
Unbuffered memory	Y
Maximum internal memory per slot	64 GB
Storage controllers
Supported storage drive types	HDD & SSD
Supported storage drive interfaces	M.2, PCI Express 4.0, PCI Express 5.0, SATA III
Number of HDDs supported	2
Number of storage drives supported	6
RAID levels	0, 1, 5, 10
RAID support	Y
Graphics
Parallel processing technology support	Not supported
On-board graphics adapter	N
Maximum resolution	4096 x 2160 Pixels
HDCP	Y
DirectX version	12.0
Internal I/O
USB 2.0 connectors	2
USB 3.2 Gen 1 (3.1 Gen 1) connectors	1
USB 3.2 Gen 2x2 connectors	1
Number of SATA III connectors	2
Front panel audio connector	Y
Front panel connector	Y
ATX Power connector (24-pin)	Y
CPU fan connector	Y
Number of chassis fan connectors	6
Peripheral (Molex) power connectors (4-pin)	1
Number of CPU fan connectors	2
EPS power connector (8-pin)	Y
Number of EPS power connectors (8-pin)	1
TPM connector	Y
12V power connector	Y
Number of water pump connectors	3
RGB LED pin header	Y
Number of temperature sensor headers	2
Number of RGB LED pin headers	4
Number of noise detection headers	1
Rear panel I/O ports
USB 2.0 ports quantity	4
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	4
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity	2
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity	1
Ethernet LAN (RJ-45) ports	1
USB4 Gen 3x2 ports quantity	2
HDMI ports quantity	1
HDMI version	2.1
DisplayPort version	1.4
Headphone outputs	1
S/PDIF out port	Y
Line-in	Y
Digital audio optical out	1
WiFi-AP antenna jack	2
Network
Ethernet LAN	Y
Ethernet interface type	2.5 Gigabit Ethernet, 5 Gigabit Ethernet, Fast Ethernet, Gigabit Ethernet
LAN controller	Realtek RTL8126
Wi-Fi	Y
Top Wi-Fi standard	Wi-Fi 7 (802.11be)
Wi-Fi standards	Wi-Fi 7 (802.11be)
WLAN controller model	Qualcomm QCNCM865
Bluetooth	Y
Bluetooth version	5.3
Features
Component for	PC
Motherboard form factor	ATX
Motherboard chipset family	AMD
Motherboard chipset	AMD X870
Audio chip	Realtek ALC1220-VB
Audio output channels	7.1 kanalen
PC health monitoring	FAN, Temperature, Voltage, Water cooling
Product colour	White
Power source type	ATX
Cooling type	Passive
Windows operating systems supported	Windows 11 x64
Expansion slots
PCI Express x16 (Gen 4. x) slots	1
PCI Express x16 (Gen 5. x) slots	1
Number of M.2 (M) slots	4
1st M.2 largest key size	25110
1st M.2 highest PCI Express generation	5.0
2nd M.2 largest key size	22110
2nd M.2 highest PCI Express generation	5.0
3rd M.2 largest key size	22110
3rd M.2 highest PCI Express generation	4.0
4th M.2 largest key size	22110
4th M.2 highest PCI Express generation	4.0
BIOS
BIOS type	UEFI AMI
BIOS memory size	512 Mbit
ACPI version	5.0
Clear CMOS jumper	Y
Desktop Management Interface (DMI) version	2.7
System Management BIOS (SMBIOS) version	2.7
Packaging data
Package width	315.5 mm
Package depth	375 mm
Package height	118.5 mm
Battery
Battery weight	3 g
Lithium weight per battery	0.07 g
Number of battery cells	1
Battery technology	Lithium-Manganese Dioxide (LiMnO2)
Battery type	CR2032
Logistics data
Country of origin	China
Quantity per shipping (inner) case	1 stuk(s)
Weight & dimensions
Width	305 mm
Depth	244 mm
Height	35 mm
Packaging content
Batteries included	Y
Screws included	Y
Antenna included	Y
Bundled software	Norton® Internet Security (OEM version)
Technical details
Warranty period	3 jaar
Other features
Weight	4400 g
Package weight	5070 g
