DesignJet Z5200PS 44 IN

Printer: print speed of up to 10.2 m²/hr (colour image, normal, coated paper), up to 2400 x 1200 optimised dpi from 600 x 600 dpi input with max. detail selected, 48 GB dedicated file-processing memory, 160 GB hard disk drive, 800 MHz processor, media width of 111.8cm
Offer large-format applications with an HP Designjet that can transform your printing experience. Impress with high-quality prints using HP inks, ColorPRO papers, and a workflow that's faster, easier, and more affordable than you thought possible.


Product id 301287
Brand Hewlett Packard
Partnr CQ113A/B19
EAN/UPC code 884962858042
Warranty (months) One-year limited hardware warranty
Print technology
Colour Y
Maximum resolution 2400 x 1200 pixels
Number of print cartridges 8
Page description languages HP-GL/2, TIFF
Print speed (normal quality) 41 m²/hr
Print quality
Minimum line width 0.08 mm
Paper handling
Maximum print size A0 (841 x 1189 mm)
Media types supported A4, A3, A2, A1, A0
Media thickness 0.8 mm
Roll paper Y
Recommended media weight 500 g/m²
Media types
Proofing paper Y
Media formats
ISO A-series sizes (A0...A9) A0, A1, A2, A3, A4
Maximum roll length 91 m
Maximum roll diameter 135 mm
Ports & interfaces
USB port Y
USB connector USB Type-A
USB 2.0 ports quantity 1
RJ-45 ports quantity 1
Internal storage capacity 160 GB
Storage media HDD
Internal memory 32768 MB
Technical details
Line accuracy +/- 0.2%
Print time colour line drawing (draft, A1) 42.1
Print time black and white line drawing (draft, metric A1 plain paper) 42.1
Media thickness (by paper path) 0.8 mm
Roll maximum input 1
Processor frequency 800 MHz
Ethernet LAN Y
Ethernet interface type Gigabit Ethernet
Power consumption (standby) 50 W
Power consumption (typical) 170 W
Operational conditions
Operating relative humidity (H-H) 20 - 80 procent
Storage relative humidity (H-H) 0 - 95 procent
Weight & dimensions
Weight 86000 g
Package weight 123000 g
System requirements
Compatible operating systems Windows 7 Home Premium/Professional/Ultimate; Windows Vista Home Premium/Business/Ultimate; Microsoft Windows XP (32-bit, 64-bit) Home/Professional, Server 2003 (32-bit, 64-bit), Server 2008 (32-bit, 64-bit); Novell NetWare 5. x, 6. x; Mac OS X v10.4, v10.5, v10.6; Citrix XenApp; Citrix XenServer
